• Ubiquiti UDM-Pro-Max rear view with 8 Ethernet ports and 2 drive bays
1 1

Ubiquiti

Ubiquiti UDM-PRO-MAX | UniFi Dream Machine Pro Max Gateway, 2x 10G SFP+, 8x GbE

Ubiquiti UDM-PRO-MAX | UniFi Dream Machine Pro Max Gateway, 2x 10G SFP+, 8x GbE

Authorised Ubiquiti Partner

UDM-Pro-Max

In stock:210

$1,253.18 inc. GST
$1,139.25 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The UniFi Dream Machine Pro Max is a 1U rack-mount cloud gateway and security gateway with an integrated 8-port Gigabit switch, 2.5GbE WAN, 2 x 10G SFP+ ports and 2 HDD bays for NVR storage. It delivers 5 Gbps IDS/IPS throughput and manages 200+ UniFi devices and 2,000+ simultaneous users, making it a strong core for small to mid-sized business networks.

Powered by a quad-core ARM Cortex-A57 processor with 8GB DDR4 memory, 32GB eMMC and an integrated 128GB SSD, it runs the UniFi Network, Protect, Access and Talk applications on one platform. Shadow Mode (VRRP) gateway redundancy, multi-WAN failover and a 1.3-inch LCM touchscreen support dependable day-to-day operation.

Features

- Stateful firewall with application-aware Layer 7 filtering and DPI
- Zone-based firewall with advanced filtering by region, domain and application
- Multi-WAN failover and load balancing
- License-free SD-WAN
- WireGuard, L2TP and OpenVPN VPN with OpenVPN and IPsec site-to-site and Teleport
- Shadow Mode (VRRP) gateway redundancy
- Redundant power input via USP-RPS (sold separately)
- RAID-protected NVR storage with 2 x 3.5" HDD bays (drives sold separately)
- WiFi QoS with UniFi access points and LTE backup failover

Warranty

Ubiquiti products come with a 1-year limited hardware warranty covering defects in materials and workmanship under normal use.

Extended Warranty Options:
Extended warranty options may be available through IP Trading. Contact our team to discuss coverage tailored to your needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 8 x 1GbE RJ45 LAN ports
- 1 x 2.5GbE RJ45 WAN port
- 2 x 10G SFP+ ports (1 WAN, 1 LAN)
- 5 Gbps IDS/IPS throughput
- Manages 200+ UniFi devices and 2,000+ simultaneous users
- Quad-core ARM Cortex-A57 at 2.0 GHz, 8GB DDR4
- 32GB eMMC plus integrated 128GB SSD
- 2 x HDD bays (2.5"/3.5") with RAID support
- Managed cameras: 50 HD / 25 2K / 15 4K
- 1.3-inch LCM touchscreen
- 1U rack mount, 442.4 x 43.7 x 285.6 mm, 4.7 kg
- Internal 100 W AC/DC power supply, 60 W maximum consumption
- Operating temperature -10 to 40 C, 5% to 95% noncondensing humidity
- Certifications: CE, FCC, IC

FAQs

Q: How many UniFi devices can the UDM-Pro-Max manage?
A: It manages 200+ UniFi devices and supports 2,000+ simultaneous connected users.

Q: What WAN options does it provide?
A: It offers a 2.5GbE RJ45 WAN port and a 10G SFP+ port that can be used as WAN, with multi-WAN failover and load balancing supported.

Q: Are hard drives included for UniFi Protect?
A: No. It has 2 HDD bays (2.5"/3.5") with RAID support for NVR storage, but drives are sold separately.

Q: Can it run UniFi Protect cameras?
A: Yes. It runs UniFi Protect and can manage up to 50 HD, 25 2K or 15 4K cameras.

Q: Does it support gateway redundancy?
A: Yes. Shadow Mode (VRRP) provides gateway redundancy, and the USP-RPS (sold separately) adds a redundant DC power input.

Q: What is the IDS/IPS throughput?
A: The UDM-Pro-Max delivers 5 Gbps IDS/IPS throughput.
