ATEN

ATEN US3311-AT-U | Duo Flex 2-Port 4K DP USB-C KVM Dock, PD 85W

ATEN US3311-AT-U | Duo Flex 2-Port 4K DP USB-C KVM Dock, PD 85W

Authorised ATEN Partner

SKU:US3311-AT-U

$265.65 inc. GST
$241.50 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The ATEN US3311-AT-U is a 2-port 4K DisplayPort USB-C KVM dock switch from the Duo Flex range, letting two USB-C computers share one DisplayPort monitor and four USB 3.2 Gen 1 Type-A peripherals. This variant has a single DisplayPort output, 85W USB-C power pass-through to charge the selected laptop, and the Australia/NZ plug.

It combines a KVM switch and multiport dock in one aluminium housing, so a hot-desking or hybrid workspace needs only one cable per laptop. Video supports 4K at up to 144/120/60 Hz or 8K 7680 x 4320 when paired with a Thunderbolt 4/USB4 host with DP 1.4, and host selection is by port switch button or hotkeys via the ATEN KVM Utility app. It is plug-and-play, with no drivers needed, and supports Windows 10+, macOS 10.12+, iPadOS 13.1+, iOS 17.1+ (iPhone 15 Pro) and Android 8.0+ with DP Alt Mode.

Features

- 2-in-1 KVM switch and multiport dock for two USB-C hosts
- One DisplayPort monitor shared between both computers
- DP 1.4 Alt Mode support
- 4K at up to 144/120/60 Hz, or 8K, with a TB4/USB4 DP 1.4 host
- 4 x USB 3.2 Gen 1 ports, up to 5 Gbps, for keyboard, mouse and storage
- USB PD 3.0 power pass-through to charge the selected laptop
- Switch hosts by port switch button or hotkeys via the ATEN KVM Utility app
- Plug-and-play, no drivers needed

Warranty

ATEN products sold by IP Trading are backed by a 24-month warranty against material defects and faulty workmanship from the date of shipment. Included accessories such as adapters and cables are covered for the same 24-month period, while batteries are covered by a 12-month warranty.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Computer connections: 2 x USB Type-C female (CPU1, CPU2)
- Device ports: 4 x USB 3.2 Gen 1 Type-A female
- Video output: 1 x DisplayPort female
- Video resolution: 3840 x 2160 at 60/120/144 Hz; 7680 x 4320
- Port 1 PD charging output: 5V, 9V, 15V, 20V
- Port 2 output: max 5V, 3A
- Power input: 1 x DC jack 12V 3.3A; 1 x USB-C PD input
- Port selection: port switch button
- LEDs: 2 (white) selected indicators
- Power consumption: DC12V 1.68W, 117 BTU/h
- Operating temperature: 0-40 C
- Storage temperature: -20-60 C
- Humidity: 0-80% RH, non-condensing
- Housing: aluminium

FAQs

Q: How many computers and monitors does the US3311-AT-U support?
A: It connects two USB-C computers and shares a single DisplayPort monitor between them.

Q: Does it charge my laptop?
A: Yes. It passes USB-C Power Delivery through to the selected laptop, with charging output on port 1 at 5V, 9V, 15V or 20V. The SKU is rated for 85W pass-through.

Q: What video resolutions are supported?
A: It supports 4K at up to 144/120/60 Hz and 8K 7680 x 4320. The highest refresh rates and 8K require a Thunderbolt 4/USB4 host with DP 1.4.

Q: How do I switch between computers?
A: Use the port switch button on the unit, or hotkeys through the ATEN KVM Utility app.

Q: Which operating systems are supported?
A: Windows 10+, macOS 10.12+, Android 8.0+ (with DP Alt Mode), iPadOS 13.1+ and iOS 17.1+ (iPhone 15 Pro).

Q: What does the AT-U suffix mean?
A: AT-U denotes the Australia/NZ plug variant of the US3311, which has a single DisplayPort output and 85W power pass-through.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
