• Backside of a black and white ubiquiti wavefiber gpon onu media converter with pon and poe in 2.5g ethernet ports
1 1

Ubiquiti

Ubiquiti WAVE-FIBER-ONU-20 | WaveFiber GPON ONU, 2.5GbE, SC/APC, 20-Pack, No PoE Injector

Ubiquiti WAVE-FIBER-ONU-20 | WaveFiber GPON ONU, 2.5GbE, SC/APC, 20-Pack, No PoE Injector

Authorised Ubiquiti Partner

WAVE-FIBER-ONU-20

In stock:6

$1,292.35 inc. GST
$1,174.86 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Ubiquiti WaveFiber GPON ONU (optical network unit) provides a 1/2.5 GbE RJ45 LAN port and an SC/APC GPON WAN port for subscriber-side fibre connections. It delivers 2.488 Gbps downstream and 1.244 Gbps upstream at distances up to 20 km, making it well suited to ISP deployments and fibre-to-the-premises rollouts. This SKU is the 20-pack and does not include a PoE injector or power supply.

The ONU is powered by 24V passive PoE and is compatible with UISP Fiber OLT XGS, UF-OLT and UF-OLT-4 equipment. Three status LEDs for PON, Ethernet and power simplify link diagnostics, and the compact polycarbonate enclosure can be placed on a desktop or mounted on a wall.

Features

- GPON ONU with a 2.5 GbE port for connecting to a fibre ISP or OLT
- Compatible with UISP Fiber OLT XGS, UF-OLT and UF-OLT-4
- Passive PoE powered (24V)
- Three signal-strength LEDs for PON link diagnostics
- Compact polycarbonate enclosure, desktop or wall mountable
- Factory reset button
- Sold in single, 5-pack and 20-pack options

Warranty

Ubiquiti products come with a 1-year limited hardware warranty covering defects in materials and workmanship under normal use.

Extended Warranty Options:
Extended warranty options may be available through IP Trading. Contact our team to discuss coverage tailored to your needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 1 x SC/APC ITU-G.984 GPON WAN port
- 1 x 1/2.5 GbE RJ45 LAN port (PoE in)
- Downstream 2.488 Gbps / Upstream 1.244 Gbps
- Operating wavelength: TX 1310 nm, RX 1490 nm
- Range up to 20 km
- Optical module TX power: 1.5 to 5 dBm, RX: -8 to -28 dBm
- Power: 24V passive PoE 2-pair, 20-28V DC, 0.3A
- Max power consumption: 5 W
- Dimensions: 76.5 x 76.5 x 26.4 mm, weight 78 g
- Polycarbonate enclosure, desktop or wall mount
- Operating temperature: -15 to 45 C, humidity 10 to 90% noncondensing
- Management: Ethernet in-band, PON
- Certifications: FCC, IC, CE
- Pack quantity: 20 units, no PoE injector or power supply included

FAQs

Q: Is a PoE injector or power supply included with this 20-pack?
A: No. This SKU contains 20 ONUs only. Each unit is powered by 24V passive PoE, so a compatible PoE injector or power supply must be sourced separately.

Q: Which OLTs is the WaveFiber ONU compatible with?
A: It is compatible with UISP Fiber OLT XGS, UF-OLT and UF-OLT-4 equipment.

Q: What fibre connector and speeds does it support?
A: It has one SC/APC GPON WAN port delivering 2.488 Gbps downstream and 1.244 Gbps upstream, plus one 1/2.5 GbE RJ45 LAN port.

Q: What is the maximum range?
A: The ONU supports distances of up to 20 km over single-mode fibre, using 1310 nm transmit and 1490 nm receive wavelengths.

Q: How is the ONU powered?
A: It uses 24V passive PoE on 2 pairs (pins 4, 5+ and 7, 8-) with a supported range of 20-28V DC and a maximum draw of 5 W.

Q: Can the ONU be wall mounted?
A: Yes. The compact polycarbonate enclosure supports both desktop placement and wall mounting.
