Moxa MGate-MB3280 | MGate MB3280 2-Port Modbus TCP to RTU/ASCII Gateway

Authorised Moxa Partner

SKU:MGate MB3280

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The MGate MB3280 is a 2-port Modbus gateway that converts between Modbus TCP and Modbus RTU/ASCII, linking serial field devices to Ethernet networks. It supports up to 16 simultaneous Modbus TCP masters and up to 31 RTU/ASCII slaves per serial port, with two software-selectable RS-232/422/485 ports and power via power jack or terminal block.

Built in a compact IP30 metal housing, the MB3280 accepts 12 to 48 VDC and operates from 0 to 60°C. Auto Device Routing and flexible routing by TCP port or IP address simplify setup, while the 1.5 kV magnetic isolation on the Ethernet port protects the connection in industrial environments.

Features

- Converts between Modbus TCP and Modbus RTU/ASCII
- Auto Device Routing for easy configuration
- Route by TCP port or IP address for flexible deployment
- 16 simultaneous TCP masters with up to 32 simultaneous requests per master
- Manages up to 62 serial slave nodes (31 per port)
- Each serial port individually configurable for RTU or ASCII and different baudrates
- Configuration via Web Console, Device Search Utility, MGate Manager or Telnet
- Management support including SNMPv1/v2c/v3, HTTPS, DHCP, NTP and SMTP

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x 10/100BaseT(X) Ethernet port (RJ45, auto MDI/MDI-X)
- 2 x RS-232/422/485 serial ports (DB9 male, software selectable)
- Modbus TCP Client (Master) and Server (Slave)
- Modbus RTU/ASCII Master and Slave
- Up to 16 TCP client connections and 32 TCP server connections
- Baudrate: 50 bps to 921.6 kbps
- Input voltage: 12 to 48 VDC, 250 mA @ 12 VDC
- Power connector: power jack and terminal block
- Metal housing, IP30
- Dimensions (without ears): 22 x 77 x 111 mm
- Weight: 360 g
- Operating temperature: 0 to 60°C
- Storage temperature: -40 to 85°C
- Magnetic isolation protection: 1.5 kV
- MTBF: 749,455 hrs (Telcordia SR332)

FAQs

Q: How many Modbus TCP masters can the MGate MB3280 support?
A: It supports up to 16 simultaneous Modbus TCP masters, with up to 32 simultaneous requests per master.

Q: How many serial slave devices can connect to the MB3280?
A: Up to 31 RTU/ASCII slaves per serial port, for a total of 62 serial slave nodes across the two ports.

Q: Which serial interfaces does the MB3280 offer?
A: It has two DB9 male serial ports, each software selectable between RS-232, RS-422 and RS-485, and each configurable independently for RTU or ASCII and baudrate.

Q: How is the MGate MB3280 powered?
A: It accepts 12 to 48 VDC through either a power jack or a terminal block.

Q: Can the MB3280 act as both a Modbus master and slave?
A: Yes. The Ethernet side supports Modbus TCP Client (Master) and Server (Slave), and the serial side supports Modbus RTU/ASCII Master and Slave.

Q: What is the operating temperature range of the MB3280?
A: The standard model operates from 0 to 60°C, in an IP30 metal housing.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
