Moxa ME-10-T | ME-10 Media Converter Chassis, 1-Slot, 12-48 VDC Redundant, -40 to 75C

Authorised Moxa Partner

SKU:ME-10-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The ME-10-T is a compact 1-slot media converter chassis from the Moxa ME-10 Series, built to house selected Moxa media converter slide-in modules. It suits industrial and harsh-environment deployments where copper and fibre-optic network media need to be bridged, with redundant 12-48 VDC power inputs and a wide -40 to 75C operating temperature range.

The module slot sits at the front of the unit and slide-in modules are hot-swappable, so modules can be changed without powering off or removing the chassis. A relay output alarm signals port break or power failure, and the chassis can be mounted on a DIN rail or on a panel.

Features

- 1-slot chassis for Moxa media converter slide-in modules
- Front-facing module slot
- Hot-swappable slide-in modules, no need to power off or remove the chassis
- Redundant dual power inputs
- Wide -40 to 75C operating range for harsh environments
- Relay output alarm contact for port break or power failure

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Number of slots: 1
- Power input: Redundant 24 VDC nominal (12 to 48 VDC)
- Operating temperature: -40 to 75 C
- Alarm: Relay output for port break or power failure
- Mounting: DIN-rail or panel mountable
- Dimensions: 18.0 x 8.94 x 2.85 cm

FAQs

Q: How many modules does the ME-10-T chassis hold?
A: The ME-10-T is a 1-slot chassis and holds a single Moxa media converter slide-in module.

Q: Does the ME-10-T support redundant power?
A: Yes. It has redundant power inputs, 24 VDC nominal with a 12 to 48 VDC range.

Q: Can modules be swapped without powering the chassis off?
A: Yes. The slide-in modules are hot-swappable, so the chassis does not need to be powered off or removed.

Q: What operating temperature does the ME-10-T support?
A: It operates from -40 to 75 C, suitable for harsh industrial environments.

Q: How is the ME-10-T mounted?
A: It can be mounted on a DIN rail or on a panel.

Q: Can the chassis alert me to a fault?
A: Yes. A relay output alarm contact signals port break or power failure.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
