Moxa IMC-P21A-G2-M-SC | IMC-P21A-G2 PoE+ Industrial Media Converter, SC Multi-Mode

Authorised Moxa Partner

SKU:IMC-P21A-G2-M-SC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The IMC-P21A-G2-M-SC is an industrial PoE+ media converter that converts 10/100BaseT(X) copper to 100BaseFX multi-mode fibre over an SC connector. It acts as power sourcing equipment (PSE), delivering up to 36 W on the PoE+ port to power an IEEE 802.3af or 802.3at device such as an IP camera or wireless access point at the end of a fibre run.

Built for industrial deployments, it has a metal IP40 housing with DIN-rail mounting, redundant dual DC power inputs and an operating range of -10 to 60°C. It supports store-and-forward and pass-through modes, with 10/100BaseT(X) auto-negotiation and auto-MDI/MDI-X on the copper port. Typical multi-mode distances reach 2 km over OM1 and 5 km over OM2, OM3 or OM4 fibre.

Features

- Converts 10/100BaseT(X) copper to 100BaseFX multi-mode fibre with SC connector
- Acts as PoE+ power sourcing equipment, up to 36 W on the copper port
- IEEE 802.3af and 802.3at standard compliance
- Supports store-and-forward and pass-through modes
- 10/100BaseT(X) auto-negotiation and auto-MDI/MDI-X
- Redundant dual DC power inputs with overload current protection
- Rugged metal housing with DIN-rail mounting for industrial cabinets
- Wide -10 to 60°C operating temperature range

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x 100BaseFX port, multi-mode, SC connector
- 1 x 10/100BaseT(X) PoE+ port, RJ45
- IEEE 802.3af PoE and 802.3at PoE+ compliant, up to 36 W output
- Fibre cable: 62.5/125 µm OM1 or 50/125 µm OM2/OM3/OM4
- Typical distance: 2 km (OM1), 5 km (OM2/OM3/OM4)
- Wavelength: 1310 nm typical
- Link budget: 12 dB multi-mode
- Input voltage: 44 to 57 VDC, redundant dual DC inputs
- Power consumption: max 828 mA
- Built-in 1.5 kV magnetic isolation protection
- Metal housing, IP40, DIN-rail mounting
- Dimensions: 90 x 73 x 20.3 mm, weight 212 g
- Operating temperature: -10 to 60°C
- Storage temperature: -40 to 85°C
- Ambient relative humidity: 5 to 95% (non-condensing)
- MTBF: 6,708,861 hrs (Telcordia SR332)

FAQs

Q: What fibre type and connector does the IMC-P21A-G2-M-SC use?
A: It uses a 100BaseFX multi-mode interface with an SC connector. It supports 62.5/125 µm OM1 or 50/125 µm OM2, OM3 and OM4 fibre.

Q: How far can it transmit over fibre?
A: Typical multi-mode distance is 2 km over OM1 and 5 km over OM2, OM3 or OM4 fibre, with a 12 dB link budget.

Q: Can it power a PoE device directly?
A: Yes. The RJ45 port is PoE+ power sourcing equipment compliant with IEEE 802.3af and 802.3at, delivering up to 36 W to a connected powered device.

Q: What power input does it require?
A: It takes 44 to 57 VDC through redundant dual DC inputs. Use above 52 VDC for PoE+ output and above 44 VDC for standard PoE output.

Q: How is it mounted?
A: It is designed for DIN-rail mounting in a metal IP40 housing, suitable for industrial cabinets and control panels.

Q: What is the difference between this and other IMC-P21A-G2 models?
A: This SKU is the multi-mode, SC connector version. Other models in the range use different fibre types or connectors, so match the fibre and connector at the far end to this unit.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
