Moxa IMC-P101-S-ST | IMC-P101 PoE Industrial Media Converter, Single-Mode ST, 40km

Authorised Moxa Partner

SKU:IMC-P101-S-ST

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa IMC-P101-S-ST is an industrial PoE media converter that converts 10/100BaseT(X) copper to 100BaseFX single-mode fibre over an ST connector, with a typical reach of 40 km. It acts as power sourcing equipment (PSE) and supplies up to 30 W to a powered device, making it well suited to powering IP cameras, wireless access points and other PoE devices at remote sites. This single-mode ST variant operates from 0 to 60°C.

Built in a metal housing with DIN-rail mounting, the IMC-P101-S-ST supports redundant dual DC power inputs and a relay output for power failure alarms. It supports both store-and-forward and pass-through modes, and offers IEEE 802.3af compliance, with IEEE 802.3at PoE+ on hardware revision 1.1.0 and later.

Features

- 10/100BaseT(X) auto-negotiation and auto-MDI/MDI-X
- IEEE 802.3af PoE standard compliance
- IEEE 802.3at PoE+ standard compliance (HW Rev. 1.1.0 and later)
- Acts as power sourcing equipment (PSE), providing up to 30 W to powered devices
- Power failure alarm by relay output
- Supports store-and-forward mode and pass-through mode
- Redundant dual DC power inputs
- Overload current protection

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x 100BaseFX port (single-mode, ST connector)
- 1 x 10/100BaseT(X) PoE port (RJ45)
- PoE PSE: IEEE 802.3af / 802.3at (PoE+ on HW Rev. 1.1.0 and later), up to 30 W
- Single-mode typical distance: 40 km
- Wavelength typical: 1310 nm
- Link budget: 29 dB
- Input voltage: 12 to 57 VDC (HW Rev. 1.1.0 and later)
- Input current: 360 mA @ 12 to 57 VDC (HW Rev. 1.1.0 and later)
- Magnetic isolation protection: 1.5 kV
- Metal housing, DIN-rail mounting
- Dimensions: 144.5 x 122.3 x 51.65 mm
- Weight: 532 g (product only)
- Operating temperature: 0 to 60°C
- Storage temperature: -40 to 85°C
- Ambient relative humidity: 5 to 95% (non-condensing)
- MTBF: 2,892,595 hrs (Telcordia SR332)

FAQs

Q: What fibre type and connector does the IMC-P101-S-ST use?
A: It has one 100BaseFX port using single-mode fibre (G.652) with an ST connector, and a typical reach of 40 km at 1310 nm.

Q: How much PoE power can it supply?
A: It acts as power sourcing equipment and can supply up to 30 W to a powered device. IEEE 802.3af is supported, and IEEE 802.3at PoE+ on hardware revision 1.1.0 and later.

Q: What power input does it accept?
A: Hardware revision 1.1.0 and later accepts 12 to 57 VDC. It has redundant dual DC power inputs and overload current protection.

Q: What is the operating temperature range?
A: This variant operates from 0 to 60°C, so it is intended for standard-temperature industrial enclosures and cabinets.

Q: How is the IMC-P101-S-ST mounted?
A: It has a metal housing and is installed using DIN-rail mounting.

Q: Does it support network speed and cable auto-detection?
A: Yes. The copper port supports 10/100BaseT(X) auto-negotiation and auto-MDI/MDI-X.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
