• Moxa EDS-208A 8-port gray industrial Ethernet switch with green LEDs
1 1

Moxa

Moxa EDS-208A-SS-SC-T | EDS-208A 8-Port Unmanaged Switch, 6x RJ45, 2x SC SM, -40 to 75C

Moxa EDS-208A-SS-SC-T | EDS-208A 8-Port Unmanaged Switch, 6x RJ45, 2x SC SM, -40 to 75C

Authorised Moxa Partner

EDS-208A-SS-SC-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The EDS-208A-SS-SC-T is a compact 8-port industrial unmanaged Ethernet switch with 6 x 10/100BaseT(X) RJ45 ports and 2 x 100BaseFX single-mode SC fibre ports. Single-mode fibre reaches up to 40 km, and the -T model is rated for a wide operating temperature range of -40 to 75°C, making it well suited to outdoor cabinets, substations, transport and maritime installations.

Redundant dual 12/24/48 VDC power inputs (9.6 to 60 VDC operating range) keep the switch running if one supply fails, and the IP30 aluminium housing mounts to a DIN rail or a wall with the optional kit. A DIP switch enables or disables broadcast storm protection, and the switch holds approvals for hazardous locations (ATEX, Class I Division 2), railway (EN 50121-4), traffic control (NEMA TS2) and maritime (ABS, LR, NK, DNV) use.

Features

- 6 x RJ45 and 2 x single-mode SC fibre connectivity in one compact unit
- Single-mode fibre uplinks reach up to 40 km with a 29 dB link budget
- Wide -40 to 75°C operating range for harsh environments
- Redundant dual 12/24/48 VDC power inputs for added reliability
- IP30 aluminium housing for rugged industrial use
- Suited to hazardous locations, transportation and maritime applications
- DIP switch to enable or disable broadcast storm protection
- Plug-and-play unmanaged operation with no configuration required
- 100% burn-in tested

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x 10/100BaseT(X) RJ45 ports with auto negotiation and auto MDI/MDI-X
- 2 x 100BaseFX single-mode SC ports, G.652 fibre, 1310 nm, up to 40 km
- Standards: IEEE 802.3, 802.3u, 802.3x flow control
- Store and forward processing, 2 K MAC table, 768 kbit packet buffer
- Redundant dual 12/24/48 VDC inputs, 9.6 to 60 VDC operating range
- Power connection: removable 4-contact terminal block, 0.15 A @ 24 VDC
- Overload current and reverse polarity protection
- Operating temperature: -40 to 75°C (-40 to 167°F)
- Storage temperature: -40 to 85°C (-40 to 185°F)
- Humidity: 5 to 95% non-condensing
- IP30 aluminium housing
- Dimensions: 50 x 114 x 70 mm, weight 275 g
- DIN-rail mounting, wall mounting with optional kit
- Approvals: ATEX, Class I Division 2, EN 50121-4, NEMA TS2, ABS, LR, NK, DNV, UL 508, EN 62368-1

FAQs

Q: What is the maximum fibre distance of the EDS-208A-SS-SC-T?
A: The two 100BaseFX single-mode SC ports support distances of up to 40 km over G.652 fibre at 1310 nm.

Q: What operating temperature range does this model support?
A: The -T model operates from -40 to 75°C (-40 to 167°F), suiting outdoor cabinets and unconditioned industrial enclosures.

Q: Is the EDS-208A-SS-SC-T a managed switch?
A: No. It is an unmanaged plug-and-play switch. The only setting is a DIP switch that enables or disables broadcast storm protection.

Q: How is the switch powered?
A: It has redundant dual 12/24/48 VDC inputs on a removable 4-contact terminal block, with an operating voltage of 9.6 to 60 VDC and reverse polarity and overload protection.

Q: How do I mount it?
A: It mounts on a DIN rail as standard. Wall mounting is possible with the optional wall-mount kit.

Q: How does it differ from the multi-mode EDS-208A variants?
A: This SKU has 2 x single-mode SC fibre ports for long-reach links up to 40 km, plus the -40 to 75°C temperature rating. Multi-mode variants use shorter-reach multi-mode ports.
