• Moxa EDS-208A-MM-SC 8-port industrial Ethernet switch with green LEDs
1 1

Moxa

Moxa EDS-208A-MM-SC | EDS-208A 8-Port Unmanaged Switch, 6x RJ45, 2x MM SC Fibre

Moxa EDS-208A-MM-SC | EDS-208A 8-Port Unmanaged Switch, 6x RJ45, 2x MM SC Fibre

Authorised Moxa Partner

EDS-208A-MM-SC

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa EDS-208A-MM-SC is a compact 8-port unmanaged industrial Ethernet switch with 6 x 10/100BaseT(X) RJ45 ports and 2 x 100BaseFX multi-mode SC fibre ports. It suits industrial automation networks that need copper device connections plus fibre links of up to 4 km over multi-mode fibre, in a standard -10 to 60°C operating temperature range.

Redundant dual 12/24/48 VDC power inputs (9.6 to 60 VDC operating range), an IP30 aluminium housing and DIN-rail mounting make it easy to deploy in control cabinets. A DIP switch enables or disables broadcast storm protection, and the unit includes overload current and reverse polarity protection. Hazardous location approvals (Class I Division 2, ATEX), railway, traffic control and maritime certifications broaden where it can be installed.

Features

- IEEE 802.3/802.3u/802.3x support with 10/100M full/half-duplex and MDI/MDI-X auto-sensing
- Combines 10/100BaseT(X) RJ45 and 100BaseFX multi-mode SC fibre connectivity
- Redundant dual 12/24/48 VDC power inputs
- Compact IP30 aluminium housing with DIN-rail mounting
- Rugged design suited to hazardous locations (Class I Div. 2 / ATEX)
- DIP switch to enable or disable broadcast storm protection
- Overload current and reverse polarity protection
- 100% burn-in tested

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x 10/100BaseT(X) RJ45 ports
- 2 x 100BaseFX multi-mode SC ports
- Standards: IEEE 802.3, 802.3u, 802.3x
- Auto negotiation speed, full/half duplex, auto MDI/MDI-X
- Multi-mode fibre: OM1 50/125 µm, typical distance 4 km, 1300 nm wavelength
- MAC table size: 2 K
- Packet buffer size: 768 kbits
- Processing type: Store and Forward
- Input voltage: 12/24/48 VDC, redundant dual inputs (9.6 to 60 VDC operating)
- Input current: 0.15 A @ 24 VDC
- Power connection: removable 4-contact terminal block
- Housing: aluminium, IP30
- Dimensions: 50 x 114 x 70 mm
- Weight: 275 g
- Mounting: DIN-rail, wall mounting with optional kit
- Operating temperature: -10 to 60°C
- Ambient relative humidity: 5 to 95% (non-condensing)
- Approvals: UL 508, EN 62368-1, ATEX, Class I Division 2, EN 50121-4, NEMA TS2, maritime (ABS, LR, NK, DNV)

FAQs

Q: Is the Moxa EDS-208A-MM-SC a managed switch?
A: No. It is an unmanaged switch. There is no software configuration, and broadcast storm protection is set with a DIP switch.

Q: What fibre connections does it support?
A: It has 2 x 100BaseFX multi-mode SC ports using OM1 50/125 µm fibre, with a typical distance of 4 km at 1300 nm.

Q: What is the operating temperature range?
A: This standard-temperature model operates from -10 to 60°C.

Q: How is the switch powered?
A: It has redundant dual 12/24/48 VDC inputs (9.6 to 60 VDC operating range) via a removable 4-contact terminal block, with overload current and reverse polarity protection.

Q: How do I mount it?
A: It mounts on a DIN-rail as standard. Wall mounting is possible with an optional kit.

Q: Can it be used in hazardous locations?
A: The EDS-208A series carries Class I Division 2 and ATEX hazardous location approvals, along with railway (EN 50121-4), traffic control (NEMA TS2) and maritime certifications.
