Fortinet FN-TRAN-SFP-1BU10 | 1G SFP BiDi Transceiver, 10km, TX 1310nm/RX 1490nm

Fortinet FN-TRAN-SFP-1BU10 | 1G SFP BiDi Transceiver, 10km, TX 1310nm/RX 1490nm

Authorised Fortinet Partner

FN-TRAN-SFP-1BU10

Stock Status: Enquire

$267.86 inc. GST
$243.51 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FN-TRAN-SFP-1BU10 is a 1 GE SFP BiDi transceiver module for long-distance fibre links of up to 10km over single-mode fibre. It uses a single LC connector and transmits on 1310nm while receiving on 1490nm, so a full duplex link runs over one fibre strand instead of two.

This module is the 1310nm-transmit end of a matched pair and connects to the FN-TRAN-1BD10 module, which is ordered separately. It suits systems with SFP slots, and the -40°C to 85°C operating range supports deployment in demanding environments.

Features

- Single-fibre bidirectional (BiDi) operation reduces fibre strand requirements
- Up to 10km reach over single-mode fibre
- Single LC connector
- Wide -40°C to 85°C operating temperature range
- Designed to pair with the FN-TRAN-1BD10 module

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 1 GE SFP BiDi transceiver
- Range: 10km
- Single LC connector, single-mode fibre (SMF)
- TX 1310nm / RX 1490nm
- Operating temperature: -40°C to 85°C
- For systems with SFP slots
- Pairs with FN-TRAN-1BD10 (ordered separately)

FAQs

Q: What module does the FN-TRAN-SFP-1BU10 pair with?
A: It connects to the FN-TRAN-1BD10 BiDi transceiver, which is ordered separately. BiDi modules work as a matched pair with opposite transmit and receive wavelengths.

Q: What distance does this transceiver support?
A: It supports links of up to 10km over single-mode fibre.

Q: What wavelengths does it use?
A: It transmits at 1310nm and receives at 1490nm.

Q: Does it need one or two fibre strands?
A: It uses a single LC connector and a single fibre strand, as the BiDi design carries transmit and receive signals on different wavelengths over the same fibre.

Q: What type of port is it designed for?
A: It is designed for systems with SFP slots and provides a 1 GE connection.

Q: What is the operating temperature range?
A: The module operates from -40°C to 85°C.
