• White Fortinet FortiGate 901G firewall rear with ports and USB
1 1

Fortinet

Fortinet FG-901G | Next-Gen Firewall, 4x 25G SFP28, 4x 10G SFP+, 1U

Fortinet FG-901G | Next-Gen Firewall, 4x 25G SFP28, 4x 10G SFP+, 1U

Authorised Fortinet Partner

FG-901G

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FG-901G is a 1U FortiGate next-generation firewall built for high-throughput enterprise and data centre edge deployments. It combines 4x 25G SFP28, 4x 10GE SFP+, 8x GE SFP and 17x GE RJ45 ports in a single rack-mount appliance, giving flexible connectivity for fibre and copper networks.

SPU NP7 network processor and CP9 content processor hardware acceleration supports demanding security workloads. Onboard 2x 480GB SSD storage, a dedicated 2.5G HA port and dual AC power supplies support local logging and resilient operation in high-availability deployments.

Features

- SPU NP7 network processor and CP9 content processor hardware acceleration
- High-density 25G SFP28 and 10G SFP+ connectivity for fibre uplinks
- Dedicated 2.5G HA port for high-availability clustering
- Integrated 16-port switch fabric on RJ45 ports
- Onboard dual 480GB SSD storage for local logging
- Dual AC power supplies for power redundancy

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 4 x 25G SFP28 slots
- 4 x 10GE SFP+ slots
- 17 x GE RJ45 ports (including 1 x MGMT port, 16 x switch ports)
- 1 x 2.5G HA port
- 8 x GE SFP slots
- SPU NP7 and CP9 hardware accelerated
- 2 x 480GB onboard SSD storage
- Dual AC power supplies
- 1U rack-mount form factor

FAQs

Q: What port types does the FG-901G provide?
A: It provides 4x 25G SFP28 slots, 4x 10GE SFP+ slots, 8x GE SFP slots and 17x GE RJ45 ports, including 1 management port and 16 switch ports. A separate 2.5G HA port is also included.

Q: Does the FG-901G include local storage?
A: Yes. It includes 2x 480GB onboard SSD storage that can be used for local logging and reporting.

Q: Is the FG-901G suitable for high-availability deployments?
A: Yes. It has a dedicated 1x 2.5G HA port and dual AC power supplies, which support clustered and power-redundant deployments.

Q: What hardware acceleration does the FG-901G use?
A: It uses Fortinet SPU technology, with the NP7 network processor and the CP9 content processor, to accelerate security and network processing.

Q: What form factor is the FG-901G?
A: It is a 1U rack-mount appliance.

Q: Do I need transceivers for the SFP28 and SFP+ slots?
A: Yes. The SFP28, SFP+ and SFP slots are empty cages that need compatible transceivers or DAC cables to match your fibre or copper links.
