Fortinet FG-7040E-DC | 7000E Next-Gen Firewall Chassis, 6RU, DC Power

Fortinet FG-7040E-DC | 7000E Next-Gen Firewall Chassis, 6RU, DC Power

Authorised Fortinet Partner

FG-7040E-DC

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FortiGate 7040E-DC is a DC-powered, 6 RU, four-slot rack-mount firewall chassis from the FortiGate 7000E Series, built for data centre, carrier and hyperscale deployments. This chassis bundle includes the system management module (shelf manager), 3x fan modules and 3x DC PSUs, and accepts two Fortinet Processor Modules (FPM) and two Fortinet Interface Modules (FIM). The FPM and FIM modules are sold separately.

A fully populated system is rated for up to 315 Gbps of firewall throughput, 160 million concurrent TCP sessions and 950,000 new sessions per second. It runs FortiOS with SPU acceleration, real-time SSL inspection including TLS 1.3, Secure SD-WAN, ZTNA enforcement and carrier-grade NAT, with support for up to 500 virtual domains and Active-Active, Active-Passive or clustered high availability.

Features

- Purpose-built SPU (Security Processing Unit) acceleration for high-performance protection
- FortiOS converged networking and security
- Real-time SSL inspection, including TLS 1.3
- Integrated Zero Trust Network Access (ZTNA) enforcement
- Dynamic segmentation and VXLAN segmentation with Layer 4 firewall rules
- Secure SD-WAN
- Carrier-grade NAT (CGNAT) and 4G/5G mobile security, including GTP-U inspection
- FortiGuard AI-powered security services
- High availability with Active-Active, Active-Passive and Clustering modes
- Supports up to 500 virtual domains (VDOMs)

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 6 RU, 19-inch rack-mount chassis with 4 slots (2x FPM slots, 2x FIM slots)
- 1x shelf manager (system management module)
- 3x DC PSUs (-48V DC, 30A per feed, 2+2 configuration) and 3x fan modules
- Firewall throughput: 315 / 310 / 200 Gbps (1518 / 512 / 64 byte UDP)
- Firewall latency (64 byte UDP): 7 μs
- Firewall throughput: 300 Mpps
- Concurrent sessions (TCP): 160 million
- New sessions per second (TCP): 950,000
- Firewall policies: 200,000
- IPsec VPN throughput (512 byte): 100 Gbps
- SSL-VPN throughput: 15 Gbps
- IPS throughput (Enterprise Mix): 60 / 100 Gbps
- NGFW throughput: 50 / 60 Gbps
- Threat Protection throughput: 40 / 48 Gbps
- Virtual domains (default / maximum): 10 / 500
- Maximum power consumption: 2500 W (1800 W average)
- Dimensions (H x W x L): 266.7 x 440 x 650 mm
- Weight: 69.6 kg
- Operating temperature: 0 to 40 C
- Certifications: FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB

FAQs

Q: What is included with the FG-7040E-DC chassis?
A: The chassis bundle includes the system management module (shelf manager), 3x fan modules and 3x DC PSUs. The FPM and FIM modules are sold separately.

Q: How many modules does the FortiGate 7040E-DC support?
A: It has four slots in total: two for Fortinet Processor Modules (FPM) and two for Fortinet Interface Modules (FIM).

Q: What power input does this model use?
A: This is the DC model. It runs from -48V DC with 30A per feed in a 2+2 configuration, with a maximum power consumption of 2500 W and an average of 1800 W.

Q: What rack space does the chassis need?
A: It is a 6 RU, 19-inch rack-mount chassis measuring 266.7 x 440 x 650 mm and weighing 69.6 kg, so plan for appropriate rack depth and lifting.

Q: What high availability options are supported?
A: Active-Active (FGSP), Active-Passive and Clustering configurations are supported.

Q: How many virtual domains can I run?
A: The system includes 10 VDOMs by default and supports up to 500.
