Fortinet FG-400G | Next-Gen Firewall, 164 Gbps, 4x 25G SFP28, Dual AC PS

Authorised Fortinet Partner

SKU:FG-400G

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The FortiGate 400G is a 1 RU next-generation firewall for mid-size enterprise and campus edge deployments. Powered by SPU NP7 and CP10 hardware acceleration, it delivers up to 164 Gbps of firewall throughput, 55 Gbps of IPsec VPN throughput and 14 Gbps of NGFW throughput. This model combines 4x 25GE SFP28, 4x 10GE SFP+, 16x GE SFP and 8x 5GE RJ45 ports with dual AC power supplies and 960 GB of onboard storage.

Dedicated 2.5GE HA and 1GE management RJ45 ports keep high availability and out-of-band administration separate from production traffic. The appliance supports up to 50 virtual domains, 96 FortiSwitches and 512 FortiAPs, making it a strong fit for consolidating security and network access at the edge of a larger site.

Features

- SPU NP7 network processor and CP10 content processor hardware acceleration
- Dual AC power supplies for power redundancy
- High-density multi-speed port mix covering 25GE SFP28, 10GE SFP+, 5GE RJ45 and GE SFP
- Dedicated 2.5GE HA and 1GE management RJ45 ports
- Onboard 960 GB storage for local logging
- Supports up to 50 virtual domains for multi-tenant segmentation
- Manages up to 96 FortiSwitches and 512 FortiAPs

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Firewall throughput: 164 / 163 / 145 Gbps (1518/512/64 byte UDP)
- IPsec VPN throughput (512 byte): 55 Gbps
- IPS throughput (enterprise mix): 25 Gbps
- NGFW throughput (enterprise mix): 14 Gbps
- Threat protection throughput (enterprise mix): 13 Gbps
- Firewall latency: 2.51 μs
- Concurrent sessions: 28 million
- New sessions per second: 580,000
- SSL VPN throughput: 6.1 Gbps
- SSL inspection throughput (IPS, avg. HTTPS): 11.5 Gbps
- Application control throughput (HTTP 64K): 50 Gbps
- Interfaces: 4x 25GE SFP28, 4x 10GE SFP+, 16x GE SFP, 8x 5GE RJ45, 1x 2.5GE RJ45 (HA), 1x GE RJ45 (MGMT)
- Local storage: 960 GB
- Power supplies: dual AC
- Form factor: 1 RU
- Virtual domains: 10 default, 50 maximum
- Max FortiAPs: 512 total, 256 tunnel mode
- Max FortiSwitches: 96

FAQs

Q: What interfaces does the FortiGate 400G have?
A: It provides 4x 25GE SFP28, 4x 10GE SFP+, 16x GE SFP and 8x 5GE RJ45 ports, plus one 2.5GE RJ45 port for HA and one GE RJ45 port for management.

Q: Does the FortiGate 400G include redundant power?
A: Yes. This model ships with dual AC power supplies in a 1 RU chassis.

Q: What firewall throughput does the FortiGate 400G deliver?
A: Firewall throughput is 164 / 163 / 145 Gbps for 1518 / 512 / 64 byte UDP packets, with 55 Gbps of IPsec VPN throughput and 14 Gbps of NGFW throughput.

Q: Does this model include local storage?
A: Yes. It includes 960 GB of onboard storage for local logging and reporting.

Q: How many virtual domains does the FortiGate 400G support?
A: It supports 10 virtual domains by default and up to 50 as a maximum.

Q: Do I need separate transceivers for the SFP and SFP28 ports?
A: Yes. The SFP28, SFP+ and SFP slots need compatible transceivers or DAC cables to be used, so select optics to match your uplink and access speeds.
