• White Fortinet FortiGate 601F with perforated panel and Ethernet ports
1 1

Fortinet

Fortinet FG-4801F-DC-NEBS | Data Centre Firewall, 8x 400GE QSFP-DD, DC Power, NEBS

Fortinet FG-4801F-DC-NEBS | Data Centre Firewall, 8x 400GE QSFP-DD, DC Power, NEBS

Authorised Fortinet Partner

FG-4801F-DC-NEBS

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The FG-4801F-DC-NEBS is a high-end data centre and carrier-class next-generation firewall built for large networks that need very high port density and DC-powered, NEBS-compliant hardware. It provides 8x 400GE/200GE QSFP-DD slots, 12x 200GE/100GE/40GE QSFP56/QSFP28 slots and 12x 50GE/25GE/10GE SFP56/SFP28 slots, with NP7 and CP9 security processors handling hardware acceleration.

This DC power variant includes four DC power supplies and NEBS Level 3 compliance, making it suited to telecom, service provider and carrier-grade environments. Two 10GE RJ45 management ports and 2x 1.92TB onboard storage support administration and logging, and the platform runs FortiOS with Fortinet Security Fabric integration.

Features

- NP7 and CP9 security processing units for hardware-accelerated performance
- DC power supplies and NEBS compliance for telecom and carrier environments
- Very high port density with 400GE, 200GE, 100GE, 50GE and 10GE connectivity
- Runs FortiOS with Fortinet Security Fabric integration

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 8 x 400GE/200GE QSFP-DD slots
- 12 x 200GE/100GE/40GE QSFP56/QSFP28 slots
- 12 x 50GE/25GE/10GE SFP56/SFP28 slots
- 2 x 10GE RJ45 management ports
- SPU NP7 and CP9 hardware acceleration
- 2 x 1.92TB onboard storage
- 4 x DC power supplies
- NEBS Level 3 compliant

FAQs

Q: What power does the FG-4801F-DC-NEBS use?
A: It is the DC-powered variant and ships with four DC power supplies, suited to telecom and carrier environments.

Q: Is this firewall NEBS compliant?
A: Yes. It is NEBS Level 3 compliant, which suits central office and carrier-grade deployments.

Q: What interface speeds does it support?
A: It provides 400GE/200GE QSFP-DD, 200GE/100GE/40GE QSFP56/QSFP28 and 50GE/25GE/10GE SFP56/SFP28 slots, plus two 10GE RJ45 management ports.

Q: Does it include onboard storage?
A: Yes. It includes 2 x 1.92TB of onboard storage.

Q: Which hardware acceleration does it use?
A: It uses Fortinet SPU NP7 network processors and CP9 content processors for hardware-accelerated security performance.

Q: Are transceivers included?
A: Transceivers are not described as included. QSFP-DD, QSFP56/QSFP28 and SFP56/SFP28 optics or DACs are selected separately to suit your links.
