Arista

Arista DCS-7060DX5-32-R | 7060X5 32-Port 400GbE QSFP-DD Switch, Rear-to-Front Airflow, 2xAC

Arista DCS-7060DX5-32-R | 7060X5 32-Port 400GbE QSFP-DD Switch, Rear-to-Front Airflow, 2xAC

Authorised Arista Partner

SKU:DCS-7060DX5-32-R

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

End of life
This item has been replaced by DCS-7050DX4-32S-R.

Description

The Arista DCS-7060DX5-32-R is a 1RU fixed-configuration 400GbE data centre switch from the 7060X5 series, with 32 QSFP-DD ports and one SFP+ port delivering 12.8 Tbps of wire-speed throughput. This -R model has rear-to-front airflow and dual AC power supplies, making it well suited to leaf or fixed-configuration spine roles in large-scale data centre networks.

Each port supports 400GbE, 200GbE, 100GbE, 50GbE, 25GbE and 10GbE speeds, with up to 128 x 100G or 128 x 25G/10G available via breakout. QSFP-DD interfaces accept industry-standard optics and cables, easing migration to 400G, and the switch runs the Arista EOS network operating system for wire-speed Layer 2 and Layer 3 forwarding and enhanced automation.

Features

- QSFP-DD interfaces support industry-standard optics and cables, easing migration to 400G
- Wire-speed Layer 2 and Layer 3 forwarding
- Suited to leaf or fixed-configuration spine roles in large-scale networks
- Runs Arista EOS network operating system
- Lower power and enhanced automation

Warranty

Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 32 x 400G QSFP-DD ports plus 1 x SFP+ port
- 1RU form factor
- 12.8 Tbps throughput (25.6 Tbps full duplex)
- Up to 5.3 Bpps packet forwarding
- 825 ns latency
- 57MB packet buffer
- Ports support 400GbE, 200GbE, 100GbE, 50GbE, 25GbE and 10GbE speeds
- Up to 128 x 100G or 128 x 25G/10G via breakout
- Rear-to-front airflow
- 2 x AC power supplies

FAQs

Q: What port types and speeds does the DCS-7060DX5-32-R offer?
A: It provides 32 x 400G QSFP-DD ports plus 1 x SFP+ port. The QSFP-DD ports support 400GbE, 200GbE, 100GbE, 50GbE, 25GbE and 10GbE speeds.

Q: Can this switch break out to lower speeds?
A: Yes. Using breakout, the switch supports up to 128 x 100G or 128 x 25G/10G ports.

Q: What does the -R suffix mean on this model?
A: The -R model has rear-to-front airflow and ships with two AC power supplies, suiting rear-intake cooling layouts in data centre racks.

Q: What throughput and latency can I expect?
A: The switch delivers 12.8 Tbps of throughput (25.6 Tbps full duplex), up to 5.3 Bpps packet forwarding and 825 ns latency, with a 57MB packet buffer.

Q: Which network operating system does it run?
A: It runs Arista EOS, with wire-speed Layer 2 and Layer 3 forwarding and enhanced automation capabilities.

Q: Where is this switch typically deployed?
A: It is designed for leaf or fixed-configuration spine roles in large-scale data centre networks, in a 1RU form factor.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
