Aruba S4B22A | CX 8325H 16p QSFP28 40G/100G Switch, Front-to-Back, AC

Aruba S4B22A | CX 8325H 16p QSFP28 40G/100G Switch, Front-to-Back, AC

Authorised Aruba Partner

S4B22A

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Aruba CX 8325H is a half-width, 1U fixed-configuration data centre switch with 16 QSFP28 40G/100G ports, running the AOS-CX operating system. This SKU has front-to-back airflow, 4 fans and 2 AC power supplies (non-TAA), making it well suited to edge, colocation and smaller data centre deployments where rack space is at a premium.

The half-width form factor allows two units to share a rack tray, and the redundant, hot-swappable fans and power supplies help maintain availability. A 2-post rack mount kit (S2T44A) is available separately for installation.

Features

- AOS-CX network operating system
- Fixed-configuration data centre switch for edge, colocation and smaller data centres
- Hot-swappable, redundant fans and power supplies
- Half-width 1U form factor, so two units can share a rack tray
- Supports 40G/100G QSFP28 ports

Warranty

Aruba Networking offers a Limited Lifetime Warranty on many of its hardware products, including select switches and access points. This warranty covers defects in materials and workmanship for the duration of the product's life, with support available for up to five years after the product's end-of-sale date.
Other Aruba products come with warranties ranging from 1 to 5 years, depending on the specific model. Warranty terms can vary based on the product category and model number.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Aruba Networking products, ensuring your network infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.hpe.com/psnow/doc/a00143138enw?jumpid=in_pdfviewer-psnow

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 16 x QSFP28 40G/100G ports
- Front-to-back airflow
- 4 x fans, 2 x AC power supplies
- Half-width 1U rack-mountable
- Switching capacity 6.4 Tbps, 2000 Mpps throughput
- 32 GB RAM
- Dimensions (W x D x H): 21.0 x 57.7 x 4.3 cm
- Weight: 6.01 kg
- Power consumption: 349 W at 100% traffic, 133 W typical, 105 W idle
- Nominal voltage 100-127V / 200-240V, 50-60 Hz
- Acoustics front-to-back: 40.1 dB LpAm
- RoHS: EN IEC 63000:2018

FAQs

Q: What ports does the CX 8325H S4B22A have?
A: It has 16 x QSFP28 ports supporting 40G and 100G.

Q: What airflow direction does this model use?
A: This SKU uses front-to-back airflow and includes 4 fans.

Q: Does it include redundant power supplies?
A: Yes, it ships with 2 AC power supplies and 4 fans, which are redundant and hot-swappable.

Q: What operating system does it run?
A: It runs the AOS-CX network operating system.

Q: Is rack mounting hardware included?
A: A 2-post rack mount kit, S2T44A, is available separately. The half-width 1U design lets two units share a rack tray.

Q: What deployments is it designed for?
A: It is a fixed-configuration data centre switch suited to edge, colocation and smaller data centre deployments.
