Arista DCS-7800R4K-36PE-LC | 7800R4K 36-Port 800GbE OSFP Line Card, TunnelSec, Large Routes
Arista DCS-7800R4K-36PE-LC | 7800R4K 36-Port 800GbE OSFP Line Card, TunnelSec, Large Routes
Authorised Arista Partner
SKU:DCS-7800R4K-36PE-LC
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista 7800R4K 36-port 800GbE OSFP line card is built for the 7800R4 Series modular data centre switch-routers, delivering up to 36 x 800GbE, 72 x 400GbE or 288 x 100GbE interfaces and 28.8 Tbps of throughput (57.6 Tbps FDX). This 7800R4K variant includes enhanced TunnelSec encryption on all ports and large-scale FlexRoute and Traffic Policies tables, making it suited to accelerated computing, data centre and service provider deployments. This SKU is the spare line card, not the version shipped installed in a chassis.
Each card provides a 32 GB port buffer and latency from 3.8 microseconds, built on a fully scheduled, lossless VOQ fabric architecture. It is supported in the DCS-7816L, DCS-7812, DCS-7808 and DCS-7804 chassis and runs Arista EOS, with MPLS, Segment Routing and EVPN-VXLAN support for large, high-performance fabrics.
Features
Features
- Fully scheduled, lossless VOQ fabric architecture that eliminates head-of-line blocking
- TunnelSec encryption: MACsec, IPsec and VXLANsec with AES-256-GCM
- FlexRoute support for over 5M routes on 7800R4K line cards
- Accelerated sFlow at 100G, 400G and 800G for visibility with no impact on forwarding
- MPLS, Segment Routing and EVPN-VXLAN support
- Runs Arista EOS
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- 36 x OSFP800 ports
- Up to 36 x 800GbE, 72 x 400GbE or 288 x 100GbE
- Throughput: 28.8 Tbps (57.6 Tbps FDX)
- Port buffer: 32 GB
- Latency: from 3.8 microseconds
- Encryption: TunnelSec on all ports
- FlexRoute: large scale
- Traffic Policies: large scale
- Accelerated sFlow: yes
- Typical (max) power: 921 W (1125 W)
- Weight: 12.1 kg (26.7 lbs)
- Dimensions (WxHxD): 48.1 x 5.4 x 45.2 cm
- Chassis support: DCS-7816L, DCS-7812, DCS-7808, DCS-7804
- Operating temperature: 0 to 40°C
- Operating altitude: 0 to 3,000 m
FAQs
Q: Which chassis support this line card?
A: The 36-port 800GbE OSFP line card is supported in the Arista DCS-7816L, DCS-7812, DCS-7808 and DCS-7804 modular chassis.
Q: What port speeds and densities does it support?
A: The card has 36 OSFP800 ports and supports up to 36 x 800GbE, 72 x 400GbE or 288 x 100GbE interfaces.
Q: What does the 7800R4K variant add over the standard line card?
A: The 7800R4K adds TunnelSec encryption on all ports and large-scale FlexRoute and Traffic Policies tables, with FlexRoute support for over 5M routes.
Q: Which encryption protocols does TunnelSec cover?
A: TunnelSec supports MACsec, IPsec and VXLANsec using AES-256-GCM.
Q: Does this SKU ship installed in a chassis?
A: No. This is the spare line card SKU, intended to be ordered separately from a chassis-bundled configuration.
Q: How much power does the line card draw?
A: Typical power draw is 921 W, with a maximum of 1125 W, which should be factored into chassis power supply planning.
