Aruba J9995A | 5400R zl2 8-Port 10GBASE-T PoE+ Smart Rate Module, MACsec v3

Authorised Aruba Partner

SKU:J9995A

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Aruba J9995A is an 8-port 1/2.5/5/10GBASE-T PoE+ Smart Rate switch module for the modular Aruba 5400R zl2 chassis. It delivers eight RJ-45 multi-gigabit ports with IEEE 802.3at PoE+ power of up to 30 W per port, making it well suited to powering Wi-Fi 5 and Wi-Fi 6 access points, IP cameras and IoT devices from a single chassis slot. As a v3 zl2 module, it provides MACsec-capable hardware.

The ports auto-negotiate 100M, 1G, 2.5G, 5G and 10G speeds over Cat5e, Cat6 and Cat6a cabling, so existing copper plant can be reused while access layer bandwidth grows. No transceivers are required, as the ports are fixed RJ-45. The module is compatible with the Aruba 5406R and 5412R zl2 chassis and supports IP SLA for Voice (UDP Jitter and UDP Jitter for VoIP), which requires v3 modules.

Features

- Smart Rate multi-gigabit bandwidth with PoE+ power for Wi-Fi 5/6 access points, cameras and IoT devices
- v3 zl2 module hardware with MACsec (IEEE 802.1AE) capability
- Supports IP SLA for Voice (UDP Jitter and UDP Jitter for VoIP), which requires v3 modules
- Auto-negotiating 100M/1G/2.5G/5G/10G ports reuse existing Cat5e/Cat6/Cat6a cabling
- Hot-swappable in the 5400R zl2 chassis
- Managed via Aruba Central, AirWave or ClearPass integration

Warranty

Aruba Networking offers a Limited Lifetime Warranty on many of its hardware products, including select switches and access points. This warranty covers defects in materials and workmanship for the duration of the product's life, with support available for up to five years after the product's end-of-sale date.
Other Aruba products come with warranties ranging from 1 to 5 years, depending on the specific model. Warranty terms can vary based on the product category and model number.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Aruba Networking products, ensuring your network infrastructure remains protected beyond the standard warranty period. Contact our team to explore options that align with your organisation's needs.
https://www.hpe.com/psnow/doc/a00143138enw?jumpid=in_pdfviewer-psnow

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 8 x RJ-45 HPE Smart Rate ports (1/2.5/5/10GBASE-T)
- Auto-negotiating 100M/1G/2.5G/5G/10G over Cat5e/Cat6/Cat6a
- IEEE 802.3at PoE+ up to 30 W per port, backwards compatible with 802.3af and pre-standard PoE
- v3 zl2 module with MACsec hardware support
- Processor: dual ARM Cortex A9 at 1 GHz
- Packet buffer: 13.5 MB internal
- Latency at 1000 Mb: under 2.8 µs (FIFO 64-byte packets)
- Latency at 10 Gbps: under 1.8 µs (FIFO 64-byte packets)
- No transceivers required (fixed RJ-45 ports)
- Compatible with Aruba 5406R and 5412R zl2 chassis
- Maximum Smart Rate ports per chassis: 48 (5406R) or 96 (5412R)
- Operating temperature (5406R chassis): 0°C to 45°C
- Storage temperature: -40°C to 70°C

FAQs

Q: Which chassis is the J9995A compatible with?
A: The J9995A is a zl2 module for the Aruba 5400R zl2 series, including the 5406R and 5412R chassis.

Q: What PoE standard does this module support?
A: It supports IEEE 802.3at PoE+ with up to 30 W per port, and is backwards compatible with 802.3af and pre-standard PoE devices.

Q: What port speeds are supported?
A: The eight RJ-45 Smart Rate ports auto-negotiate 100M, 1G, 2.5G, 5G and 10G speeds over Cat5e, Cat6 and Cat6a copper cabling.

Q: Do I need transceivers for this module?
A: No. The module has fixed RJ-45 ports, so no transceivers are required.

Q: How many Smart Rate ports can a chassis support?
A: A 5406R chassis supports up to 48 Smart Rate multi-gigabit ports and a 5412R supports up to 96.

Q: What does v3 mean for this module?
A: v3 refers to the third generation of zl2 module hardware. It provides MACsec-capable hardware and is required for features such as IP SLA for Voice (UDP Jitter and UDP Jitter for VoIP).
