Moxa EDS-4009-3MST-HV | EDS-4009 9-Port Managed Switch, 3x 100BaseFX ST

Authorised Moxa Partner

SKU:EDS-4009-3MST-HV

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa EDS-4009-3MST-HV is a Layer 2 managed industrial Fast Ethernet switch with nine ports: six 10/100BaseT(X) RJ45 copper ports and three 100BaseFX multi-mode ports with ST connectors. It suits factory floors, utilities and transport sites that need fibre uplinks over multi-mode cabling alongside copper device connections. This variant has a single 110/220 VAC/VDC power input and an operating temperature range of -10 to 60°C.

Built in an IP40 metal housing for DIN-rail mounting, it measures just 55 x 140 x 132 mm and fits confined cabinets. Turbo Ring, Turbo Chain and RSTP/STP provide network redundancy, and MXstudio supports visualised industrial network management. The switch is certified to IEC 62443-4-2 Security Level 2.

Features

- Turbo Ring and Turbo Chain with recovery time under 20 ms at 250 switches
- RSTP/STP support for network redundancy
- Wide-range power input for flexible deployment
- Compact housing design fits into confined spaces
- Supports MXstudio for visualised industrial network management
- IEC 62443-4-2 Security Level 2 certified

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x 10/100BaseT(X) RJ45 ports with auto-negotiation, full/half duplex and auto MDI/MDI-X
- 3 x 100BaseFX multi-mode ports with ST connectors
- MAC table size: 16 K
- Jumbo frame size: 9.216 KB
- Single power input: 110/220 VAC/VDC
- Operating temperature: -10 to 60°C
- Overload current protection and reverse polarity protection
- IP40 metal housing
- Dimensions: 55 x 140 x 132 mm
- Weight: 920 g
- DIN-rail mounting, wall mounting with optional kit
- ESD contact 8 kV / air 15 kV, surge 4 kV on power and signal

FAQs

Q: What fibre connectors and cable type does the EDS-4009-3MST-HV use?
A: It has three 100BaseFX multi-mode ports with ST connectors, so it uses multi-mode fibre terminated with ST.

Q: How many copper ports does it have?
A: It has six 10/100BaseT(X) RJ45 ports with auto-negotiation and auto MDI/MDI-X.

Q: What power input does this model use?
A: It has a single 110/220 VAC/VDC power input. It does not provide a redundant power input.

Q: What operating temperature range is supported?
A: This standard-temperature variant operates from -10 to 60°C.

Q: Does it support ring redundancy?
A: Yes. Turbo Ring and Turbo Chain, with recovery time under 20 ms at 250 switches, and RSTP/STP are supported.

Q: How is the switch mounted?
A: It mounts on a DIN rail. Wall mounting is possible with an optional kit.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
