Moxa EDS-4008-LV-T | EDS-4008 8-Port Managed Switch, 12/24/48 VDC, -40 to 75 C

Authorised Moxa Partner

SKU:EDS-4008-LV-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The EDS-4008-LV-T is an industrial 8-port managed Ethernet switch with 8 x 10/100BaseT(X) RJ45 ports, built for DIN-rail installation in harsh environments. This wide-temperature model is rated for -40 to 75 °C and ships with the PWR-100-LV power module for 12/24/48 VDC supply (9.6 to 60 VDC operating range), making it well suited to factory automation, transport and utility cabinets.

The IP40 metal housing supports DIN-rail or wall mounting (optional kit). Layer 2 management includes VLAN, IGMP Snooping, SNMPv1/v2c/v3 and Turbo Ring v2 / Turbo Chain redundancy, alongside EtherNet/IP, Modbus TCP and PROFINET IO device support for industrial automation networks. The switch carries IEC 62443-4-2 Security Level 2 certification.

Features

- Modular power supply design; power parameters are set by the installed power module
- Layer 2 managed switching with VLAN (802.1Q), IGMP Snooping, GMRP/GVRP
- Network redundancy with Turbo Ring v2, Turbo Chain, RSTP/MSTP and MRP
- STP, Ring Coupling, Dual-Homing and Link Aggregation support
- EtherNet/IP, Modbus TCP and PROFINET IO device support for industrial automation
- SNMPv1/v2c/v3, RMON, LLDP, port mirroring, syslog and HTTPS/SFTP management
- IEC 62443-4-2 Security Level 2 cybersecurity certification
- Wide operating temperature of -40 to 75 °C

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x 10/100BaseT(X) RJ45 ports, auto negotiation, full/half duplex, auto MDI/MDI-X
- No fibre, Gigabit/SFP or PoE ports
- Pre-installed power module: PWR-100-LV
- Operating voltage: 9.6 to 60 VDC (12/24/48 VDC)
- Power connection: 2 removable 4-contact terminal blocks
- Input current: 12-48 VDC, 1.50-0.40 A or 24 VDC, 0.70 A
- Power consumption (max.): 7.20 W
- Overload current and reverse polarity protection supported
- Operating temperature: -40 to 75 °C (-40 to 167 °F)
- Storage temperature: -40 to 85 °C (-40 to 185 °F)
- Ambient relative humidity: 5 to 95% (non-condensing)
- IP40 rated metal housing
- Dimensions: 55 x 140 x 120 mm
- Weight: 857 g
- Mounting: DIN-rail, or wall mount with optional kit
- MTBF: 1,121,399 hrs (Telcordia SR-332)
- Cybersecurity: IEC 62443-4-2 Security Level 2, IEC 61162-460 (switch role)
- Safety: UL 61010-2-201, EN 62368-1 (LVD)
- EMC: EN 55032/35, EN 61000-6-2/-6-4

FAQs

Q: What power supply does the EDS-4008-LV-T use?
A: It ships with the PWR-100-LV power module pre-installed, supporting 12/24/48 VDC with an operating range of 9.6 to 60 VDC via two removable 4-contact terminal blocks.

Q: What operating temperature range does this switch support?
A: This is the wide-temperature (-T) model, rated for operation from -40 to 75 °C.

Q: Does the EDS-4008-LV-T have fibre, SFP or PoE ports?
A: No. It provides 8 x 10/100BaseT(X) RJ45 ports only, with no fibre, Gigabit/SFP or PoE ports.

Q: Which industrial protocols and redundancy options are supported?
A: It supports EtherNet/IP, Modbus TCP and PROFINET IO device, plus STP, RSTP, MSTP, Turbo Ring v2, Turbo Chain, Ring Coupling, Dual-Homing, Link Aggregation and MRP.

Q: How is the switch mounted?
A: It mounts on a DIN rail, or on a wall using the optional wall-mount kit. The housing is metal with an IP40 rating.

Q: Does it meet industrial cybersecurity standards?
A: Yes. It is certified to IEC 62443-4-2 Security Level 2 and IEC 61162-460 (switch role).

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
