• Moxa EDS-508A managed Ethernet switch with black teal panel, silver casing
1 1

Moxa

Moxa EDS-508A-SS-SC-80-T | EDS-508A 8-Port Managed Switch, 2x SC SM 80km, -40 to 75C

Moxa EDS-508A-SS-SC-80-T | EDS-508A 8-Port Managed Switch, 2x SC SM 80km, -40 to 75C

Authorised Moxa Partner

EDS-508A-SS-SC-80-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The EDS-508A-SS-SC-80-T is an 8-port Layer 2 managed industrial Ethernet switch with 6 x 10/100BaseT(X) RJ45 ports and 2 x 100BaseFX single-mode SC fibre ports supporting links of up to 80 km. This wide-temperature model operates from -40 to 75°C, making it well suited to long-distance fibre backbones in harsh industrial environments such as substations, tunnels and remote pumping sites.

Built in an IP30 metal housing with DIN-rail mounting, it accepts redundant 12/24/48 VDC dual power inputs with reverse polarity and overload protection. Turbo Ring and Turbo Chain redundancy, VLAN, IGMP, QoS and SNMP management, plus HTTPS, SSH, RADIUS and TACACS+ security, provide the resilience and control needed for mission-critical industrial networks.

Features

- 80 km single-mode fibre reach for long-distance industrial links
- Wide-temperature operation from -40 to 75°C
- Turbo Ring and Turbo Chain fast redundancy protocols
- Redundant dual power inputs with reverse polarity and overload protection
- Layer 2 managed with VLAN, IGMP, QoS and SNMP
- HTTPS, SSH, RADIUS and TACACS+ security
- IEEE 1588v2 PTP (software-based) time synchronisation
- DIP switch configuration for Turbo Ring, Master, Coupler and Reserve
- Supports the optional ABC-01 automatic backup configurator

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x 10/100BaseT(X) RJ45 ports, auto negotiation, auto MDI/MDI-X
- 2 x 100BaseFX single-mode SC ports, 80 km on G.652 fibre
- Input voltage: 12/24/48 VDC redundant dual inputs, operating range 9.6 to 60 VDC
- Input current: 0.30 A @ 24 VDC
- Reverse polarity and overload current protection
- IP30 metal housing, DIN-rail mounting, wall mounting with optional kit
- Dimensions: 80.2 x 135 x 105 mm, weight 1040 g
- Operating temperature: -40 to 75°C, storage -40 to 85°C
- Humidity: 5 to 95% non-condensing
- MAC table 8 K, 64 VLANs (VID 1 to 4094), 256 IGMP groups
- Packet buffer 1 Mbits, 4 priority queues
- Redundancy: STP, RSTP, MSTP, LACP, Turbo Ring v1/v2, Turbo Chain
- Security: HTTPS/SSL, SSH, RADIUS, TACACS+, Port Lock
- Time management: NTP, SNTP, IEEE 1588v2 PTP (software-based)

FAQs

Q: What fibre type and distance does this switch support?
A: The two 100BaseFX SC ports are single-mode and support links of up to 80 km over G.652 fibre.

Q: What operating temperature range does the EDS-508A-SS-SC-80-T support?
A: It is a wide-temperature model rated for operation from -40 to 75°C.

Q: Does this switch provide PoE?
A: No. The six RJ45 ports are standard 10/100BaseT(X) ports without Power over Ethernet.

Q: Can it be powered redundantly?
A: Yes. It has dual redundant 12/24/48 VDC inputs on removable terminal blocks, with an operating range of 9.6 to 60 VDC.

Q: Which redundancy protocols are supported?
A: It supports Turbo Ring v1/v2, Turbo Chain, STP, RSTP, MSTP and LACP link aggregation.

Q: How is the switch mounted?
A: It is DIN-rail mounted as standard, and wall mounting is available with an optional kit.
