• Moxa EDS-408A-3M-SC-T switch with metallic chassis, teal panels, green caps
1 1

Moxa

Moxa EDS-408A-3M-SC-T | EDS-408A Managed Industrial Switch, 5x RJ45, 3x SC MM, -40 to 75C

Moxa EDS-408A-3M-SC-T | EDS-408A Managed Industrial Switch, 5x RJ45, 3x SC MM, -40 to 75C

Authorised Moxa Partner

EDS-408A-3M-SC-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa EDS-408A-3M-SC-T is an entry-level Layer 2 managed industrial Ethernet switch with 5 x 10/100BaseT(X) RJ45 ports and 3 x 100BaseFX multi-mode SC fibre ports. The wide-temperature -T design operates from -40 to 75°C, suiting outdoor cabinets, factory floors and other harsh environments where copper and fibre connectivity are needed in one compact DIN-rail unit.

Turbo Ring, Turbo Chain and RSTP/STP provide network redundancy, with recovery times under 20 ms at 250 switches. VLAN, QoS and IGMP snooping support, plus EtherNet/IP and Modbus TCP, make it straightforward to integrate into industrial automation networks. Redundant dual 12/24/48 VDC inputs and an IP30 metal housing add reliability.

Features

- Turbo Ring and Turbo Chain (recovery under 20 ms at 250 switches) plus RSTP/STP for network redundancy
- IGMP snooping, QoS, IEEE 802.1Q VLAN and port-based VLAN
- Management via web browser, CLI, Telnet/serial console, Windows utility and ABC-01
- MXstudio support for visualised industrial network management
- DHCP Option 82 for flexible IP address assignment policies
- EtherNet/IP and Modbus TCP support for device management and monitoring
- Port mirroring for online debugging
- RMON and SNMPv1/v2c/v3 for network monitoring and security
- Bandwidth management to prevent unpredictable network status
- Relay alarm and email warning

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 5 x 10/100BaseT(X) RJ45 ports
- 3 x 100BaseFX multi-mode SC ports, 8 ports total
- Layer 2 managed
- Multi-mode fibre: OM1 50/125 µm, typical distance 4 km, 1300 nm wavelength
- Link budget 12 dB (multi-mode)
- MAC table size 8 K, 64 VLANs (VID 1 to 4094), 256 IGMP groups
- Packet buffer 1 Mbits, 4 priority queues
- Redundant dual 12/24/48 VDC inputs, operating voltage 9.6 to 60 VDC
- Input current 0.35 A @ 24 VDC
- Overload current and reverse polarity protection
- Relay alarm contact, 1 A @ 24 VDC
- RS-232 console port (10-pin RJ45)
- IP30 metal housing
- Dimensions 53.6 x 135 x 105 mm, weight 890 g
- DIN-rail mounting, wall mounting with optional kit
- Operating temperature -40 to 75°C
- Storage temperature -40 to 85°C
- Humidity 5 to 95% non-condensing
- MTBF 1,253,072 hrs (Telcordia)

FAQs

Q: What fibre connectors and cable does the EDS-408A-3M-SC-T use?
A: It has 3 x 100BaseFX multi-mode ports with SC connectors, designed for OM1 50/125 µm fibre with a typical reach of 4 km at 1300 nm.

Q: What is the operating temperature range?
A: The -T wide-temperature model operates from -40 to 75°C, suitable for harsh industrial environments.

Q: Does this switch support ring redundancy?
A: Yes. It supports Turbo Ring v1/v2 and Turbo Chain with recovery times under 20 ms at 250 switches, as well as RSTP and STP.

Q: How is the switch powered?
A: It has redundant dual inputs accepting 12/24/48 VDC (operating range 9.6 to 60 VDC) via a removable 6-contact terminal block, with overload and reverse polarity protection.

Q: How is the switch mounted and what is its protection rating?
A: It mounts on a DIN rail, or on a wall with the optional kit, and has an IP30 metal housing.

Q: Which industrial protocols are supported?
A: EtherNet/IP and Modbus TCP are supported for device management and monitoring, which helps integration with PLC and SCADA systems.
