Moxa EDS-408A-3S-SC-48 | EDS-408A Managed Switch, 5x RJ45, 3x SC SM, 48VDC

Authorised Moxa Partner

SKU:EDS-408A-3S-SC-48

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The EDS-408A-3S-SC-48 is a Layer 2 managed industrial Ethernet switch with 5 x 10/100BaseT(X) RJ45 ports and 3 x 100BaseFX single-mode SC fibre ports. It runs from redundant ±24/±48 VDC power inputs and suits industrial automation, transport and utility networks that need long-reach fibre links of up to 40 km.

Built in a compact IP30 metal housing for DIN-rail mounting, it supports Turbo Ring, Turbo Chain and RSTP/STP redundancy, along with EtherNet/IP and Modbus TCP protocol support. Secure management over HTTPS/SSL, SSH and SNMPv3 and a relay alarm output make it a dependable entry-level managed switch for control cabinets and field installations.

Features

- Turbo Ring v1/v2 and Turbo Chain network redundancy
- RSTP/STP support for loop-free topologies
- EtherNet/IP and Modbus TCP industrial protocol support
- IPv4/IPv6, SNMPv1/v2c/v3, LLDP, port mirroring and RMON
- HTTPS/SSL and SSH secure management with port lock and trust access control
- 802.1Q VLAN, GMRP, GVRP and IGMP v1/v2 filtering
- Redundant dual power inputs with relay alarm output
- DIP switch configuration for Turbo Ring

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 5 x 10/100BaseT(X) RJ45 ports with auto negotiation and auto MDI/MDI-X
- 3 x 100BaseFX single-mode SC ports, 1310 nm, typical distance 40 km
- Input voltage: ±24/±48 VDC, redundant dual inputs (operating range ±19 to ±60 VDC)
- MAC table size: 8 K, up to 64 VLANs, 1 Mbits packet buffer, 4 priority queues
- Relay alarm output, 1 A @ 24 VDC
- RS-232 console port (10-pin RJ45)
- IP30 metal housing, DIN-rail mounting (wall mounting with optional kit)
- Dimensions: 53.6 x 135 x 105 mm, weight 890 g
- Operating temperature: -10 to 60°C
- Storage temperature: -40 to 85°C
- Safety: UL 508, EMC: EN 55032/35, Railway: EN 50121-4
- MTBF: 989,940 hrs (Telcordia)

FAQs

Q: What fibre type and distance does the EDS-408A-3S-SC-48 support?
A: It has 3 x 100BaseFX single-mode SC ports operating at 1310 nm, with a typical distance of 40 km.

Q: What power input does this model use?
A: It accepts redundant dual ±24/±48 VDC inputs through a removable 6-contact terminal block, with an operating range of ±19 to ±60 VDC.

Q: Which redundancy protocols are supported?
A: It supports Turbo Ring v1/v2, Turbo Chain, RSTP and STP.

Q: How is it mounted?
A: It mounts on a DIN rail as standard. Wall mounting is possible with an optional kit.

Q: What is the operating temperature range for this SKU?
A: This model is rated for -10 to 60°C operation.

Q: Which industrial protocols does it support?
A: It supports EtherNet/IP and Modbus TCP for integration with industrial automation systems.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
