Moxa EDS-408A-MM-ST | EDS-408A 8-Port Managed Industrial Switch, 2x 100BaseFX MM ST

Authorised Moxa Partner

SKU:EDS-408A-MM-ST

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa EDS-408A-MM-ST is an entry-level Layer 2 managed industrial Ethernet switch with 6 x 10/100BaseT(X) copper ports and 2 x 100BaseFX multi-mode ports with ST connectors. The multi-mode fibre ports allow you to extend an industrial network over fibre while the copper ports connect local devices such as PLCs, HMIs and controllers.

Built for control cabinets and field enclosures, it features a metal IP30 housing, DIN-rail mounting and redundant dual 12/24/48 VDC power inputs. The 0 to 60 °C operating temperature range suits standard industrial environments, and the managed feature set supports resilient, monitored network deployments.

Features

- Redundant dual power inputs for improved uptime
- Managed Layer 2 switching for industrial networks
- Multi-mode fibre ports with ST connectors for fibre uplinks
- Rugged metal IP30 housing with DIN-rail mounting

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x 10/100BaseT(X) ports
- 2 x 100BaseFX multi-mode ports, ST connector
- 8 ports total, Layer 2 managed
- Redundant dual 12/24/48 VDC power inputs
- Input current: 0.61 A @ 12 VDC, 0.3 A @ 24 VDC, 0.16 A @ 48 VDC
- Operating temperature: 0 to 60 °C (32 to 140 °F)
- IP30 metal housing
- DIN-rail mount

FAQs

Q: What fibre connections does the EDS-408A-MM-ST provide?
A: It has 2 x 100BaseFX multi-mode ports with ST connectors, alongside 6 x 10/100BaseT(X) copper ports.

Q: Is the EDS-408A-MM-ST a managed switch?
A: Yes, it is an entry-level Layer 2 managed industrial Ethernet switch.

Q: What power inputs does it support?
A: It has redundant dual 12/24/48 VDC power inputs, so it can stay powered if one supply fails.

Q: What is the operating temperature range?
A: The standard-temperature model operates from 0 to 60 °C (32 to 140 °F).

Q: How is the switch mounted?
A: It is designed for DIN-rail mounting and has a metal IP30 housing.

Q: Does this switch provide PoE?
A: No, this model does not supply Power over Ethernet. Powered devices need a separate power source or injector.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
