Description

The Moxa EDS-P206A-4PoE-SS-SC is a 6-port unmanaged industrial PoE+ Ethernet switch with four IEEE 802.3af/at PoE ports delivering up to 30 W each, one 10/100BaseT(X) RJ45 port and two 100BaseFX single-mode SC fibre ports with a typical reach of 40 km. It operates across -10 to 60°C, making it suited to powering IP cameras, wireless access points and other PoE devices over long fibre uplinks in factory, transport and utility environments.

The metal IP30 housing mounts on a DIN rail, with wall mounting available using an optional kit. Redundant 12/24/48 VDC power inputs, reverse polarity protection and overload current protection support dependable operation, and intelligent power consumption detection and classification manage PoE loads automatically.

Features

- IEEE 802.3af/at compliant PoE and Ethernet combo ports
- Up to 30 W output per PoE port
- Two single-mode SC fibre ports for 40 km uplinks
- 12/24/48 VDC redundant dual power inputs
- Intelligent power consumption detection and classification
- Metal housing with DIN-rail mounting
- Reverse polarity and overload current protection

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x 10/100BaseT(X) RJ45 port
- 4 x 10/100BaseT(X) PoE/PoE+ RJ45 ports (IEEE 802.3af/at)
- 2 x 100BaseFX single-mode SC ports
- Maximum PoE output: 30 W per port
- Typical single-mode fibre distance: 40 km (G.652 fibre, 1310 nm)
- Power inputs: 12/24/48 VDC redundant
- Power consumption: 13.2 W at full load, excluding powered device consumption
- Housing: metal, IP30
- Dimensions: 50.3 x 114 x 70 mm
- Weight: 375 g
- Installation: DIN-rail mounting, wall mounting with optional kit
- Operating temperature: -10 to 60°C
- Storage temperature: -40 to 85°C
- Ambient relative humidity: 5 to 95% (non-condensing)
- Safety: UL 508
- MTBF: 1,289,258 hrs (Telcordia/Bellcore, GB)

FAQs

Q: How many PoE ports does the EDS-P206A-4PoE-SS-SC have?
A: It has four 10/100BaseT(X) PoE/PoE+ ports compliant with IEEE 802.3af/at, each delivering up to 30 W.

Q: What fibre type and distance does this model support?
A: The two 100BaseFX SC ports are single-mode, using G.652 fibre at 1310 nm, with a typical distance of 40 km.

Q: Is this a managed switch?
A: No. It is an unmanaged switch, so it needs no configuration and works plug and play.

Q: What power input does it require?
A: It accepts redundant 12/24/48 VDC inputs. Power consumption is 13.2 W at full load, not including the consumption of connected powered devices.

Q: How is it mounted?
A: It mounts on a DIN rail, and wall mounting is available with an optional kit.

Q: What temperature range does this SKU support?
A: This model operates from -10 to 60°C.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
