Moxa EDS-208A-M-SC-T Unmanaged Ethernet Switch With 7 10/100Baset(X) Ports, 1 100Basefx Multi-Mode Port With Sc Connector, -40 To 75 C Operating Temperature

The Moxa EDS-208A-M-SC-T is a rugged, unmanaged Ethernet switch designed for industrial applications. It features seven 10/100BaseT(X) ports and one 100BaseFX multi-mode port with an SC connector, ensuring reliable and flexible network connectivity. Built to withstand extreme conditions, the switch operates efficiently in temperatures ranging from -40 to 75°C. Its robust design and dependable performance make it ideal for demanding environments in automation and transportation sectors. Enjoy seamless integration and uninterrupted data communication with the Moxa EDS-208A-M-SC-T.

REQUEST A QUOTE today, and let us provide you with a prompt and professional response tailored just for you. Experience the highest standard of service at unbeatable prices.

Moxa EDS-208A-M-SC-T Unmanaged Ethernet Switch With 7 10/100Baset(X) Ports, 1 100Basefx Multi-Mode Port With Sc Connector, -40 To 75 C Operating Temperature

Features

  • Unmanaged Ethernet switch with industrial-grade design
  • 7 10/100BaseT(X) ports for flexible network connectivity
  • 1 100BaseFX multi-mode port with SC connector
  • Wide operating temperature range from -40 to 75°C
  • DIN-rail mountable for easy installation
  • Designed to withstand harsh industrial environments
  • Plug-and-play simplicity

Technical Specifications

  • Model: EDS-208A-M-SC-T
  • Port Type:
    • 7 RJ45 10/100BaseT(X)
    • 1 SC 100BaseFX multi-mode
  • Fiber Mode: Multi-mode
  • Connector Type: SC
  • Switching Capacity: 1.6 Gbps
  • Packet Forwarding Rate: 1.2 Mpps
  • Dimensions: 53.6 x 135 x 105 mm (W x H x D)
  • Weight: 590 g
  • Power Input: 12 to 48 VDC
  • Operating Temperature: -40 to 75°C
  • Storage Temperature: -40 to 85°C
  • MTBF: 582,567 hours
  • Humidity: 5% to 95% RH (non-condensing)
  • EMI: FCC Part 15, CISPR 32
  • EMS: IEC 61000-4-2 (ESD), IEC 61000-4-3 (RS), IEC 61000-4-4 (EFT), IEC 61000-4-5 (Surge), IEC 61000-4-6 (CS), IEC 61000-4-8

Frequent Ask Questions

  • What are the main features of the Moxa EDS-208A-M-SC-T Ethernet Switch?

    The Moxa EDS-208A-M-SC-T Ethernet Switch features 7 10/100BaseT(X) ports and 1 100BaseFX multi-mode port with SC connector. It is designed for a wide operating temperature range of -40 to 75°C, making it suitable for harsh industrial conditions.

  • Is the Moxa EDS-208A-M-SC-T an unmanaged switch?

    Yes, the Moxa EDS-208A-M-SC-T is an unmanaged Ethernet switch.

  • What type of connector is used for the fiber port on the Moxa EDS-208A-M-SC-T?

    The Moxa EDS-208A-M-SC-T uses an SC connector for its 100BaseFX multi-mode fiber port.

  • What is the power input requirement for the Moxa EDS-208A-M-SC-T?

    The Moxa EDS-208A-M-SC-T requires a power input of 12 to 48 VDC.

  • Can the Moxa EDS-208A-M-SC-T operate in extreme temperatures?

    Yes, the Moxa EDS-208A-M-SC-T supports an operating temperature range of -40 to 75°C, making it ideal for use in extreme industrial environments.

  • How does the Moxa EDS-208A-M-SC-T ensure reliable performance in industrial applications?

    The Moxa EDS-208A-M-SC-T is designed to offer reliable performance with features such as a rugged metal housing, wide temperature range, and compliance with various industrial standards to ensure consistent operation in demanding environments.
