Ubiquiti UACC-UPS-2U-BATTERY | UniFi UPS 2U Hot-Swap Replacement Battery, 216Wh, 24V

Authorised Ubiquiti Partner

SKU:UACC-UPS-2U-Battery

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The UniFi UPS 2U replacement battery is a hot-swappable 216Wh, 24V DC lead-acid battery module (2 x 12V 9Ah) designed for the UniFi UPS 2U rackmount uninterruptible power supply. It restores the full runtime of a tired UPS without powering it down, so connected network equipment stays online during the swap.

Dedicated GPS40 AFP connectors provide secure power transfer to the UPS, and the ABS enclosure measures 222 x 169 x 67 mm and weighs 5.5 kg. It is a field-replaceable part that suits rack deployments where uptime matters and routine battery replacement needs to be quick and simple.

Features

- Hot-swappable replacement for the UniFi UPS 2U without interrupting power to connected devices
- Field-replaceable design restores the UPS's full capacity and runtime
- Pairs with the UPS 2U, which offers up to 8 minutes runtime at half load (500W)
- Dedicated GPS40 AFP connectors for secure power transfer to the UPS

Warranty

Ubiquiti products come with a 1-year limited hardware warranty covering defects in materials and workmanship under normal use.

Extended Warranty Options:
Extended warranty options may be available through IP Trading. Contact our team to discuss coverage tailored to your needs.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Capacity: 216Wh
- Battery type: Lead-acid, 2 x 12V 9Ah
- Nominal voltage: 24V DC
- Connectors: GPS40 AFP
- Hot-swappable design
- Enclosure material: ABS
- Dimensions (W x D x H): 222 x 169 x 67 mm
- Weight: 5.5 kg
- Operating temperature: 0 to 40 C
- Operating humidity: 20 to 95% non-condensing
- Storage temperature: -15 to 50 C
- Compatible with: UniFi UPS 2U (UPS-2U)

FAQs

Q: Which UPS is this battery compatible with?
A: It is designed for the UniFi UPS 2U (UPS-2U) rackmount uninterruptible power supply.

Q: Can I replace the battery without shutting down the UPS?
A: Yes. The module is hot-swappable, so it can be replaced without powering down the UPS or interrupting power to connected devices.

Q: What is the battery capacity and chemistry?
A: It provides 216Wh using two 12V 9Ah lead-acid batteries, delivering 24V DC nominal output.

Q: What connectors does the battery use?
A: It uses GPS40 AFP input and output connectors to transfer power to the UPS.

Q: How much does the battery weigh and what are its dimensions?
A: It weighs 5.5 kg and measures 222 x 169 x 67 mm (W x D x H).

Q: What runtime can I expect with the UPS 2U?
A: The UniFi UPS 2U offers up to 8 minutes of runtime at half load (500W) with a healthy battery.
