• Eaton PWHR1234WFR 12V 34W 9Ah UPS battery gray with blue label silver terminals
1 1

Eaton

Eaton 52UPS12V34WFR | Powerware UPS Battery, 12V 9Ah, 34W, F2 Top Terminal, FR

Eaton 52UPS12V34WFR | Powerware UPS Battery, 12V 9Ah, 34W, F2 Top Terminal, FR

Authorised Eaton Partner

52UPS12V34WFR

In stock:191

$37.71 inc. GST
$34.28 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

This Eaton Powerware 12V 9Ah UPS replacement battery is a sealed VRLA lead-acid service battery rated at 34W per cell at the 15-minute rate. It features F2 top terminals and a high-discharge, flame-retardant (FR) design suited to select Eaton UPS units, making it a straightforward like-for-like swap when a UPS battery reaches end of life.

The compact, lightweight construction delivers high power density for UPS applications and can be installed using existing UPS cabling. It is equivalent to the Powerware PWHR1234W2FR and is built from UL-recognised components under ISO 9001 and ISO 14001 certified manufacturing.

Features

- High power density design for UPS applications
- Small volume, lightweight, high discharge efficiency
- Rated for more than 260 cycles at 100% discharge in cycle service
- UL-recognised components (UL924), ISO 9001 and ISO 14001 certified
- Wide operating temperature range and long expected service life
- Can be installed using existing UPS cabling

Warranty

• Standard UPS (with VRLA batteries): 2–3 year warranty
• Lithium-ion UPS (up to 3kVA): 5-year warranty
Extended Warranty Options:
Extended Eaton UPS warranties are available through IP Trading. Contact us to discuss a plan that suits your power protection needs.
https://www.eaton.com/us/en-us/catalog/services/ups-services/understanding-your-eaton-ups-warranty-.html

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Replacement Battery Finder

Technical Specifications

- Nominal voltage: 12V (6 cells per unit)
- Capacity: 9Ah
- Power rating: 34W per cell at 15-minute rate to 1.67V/cell at 25°C
- Chemistry: sealed lead acid (VRLA)
- Terminal: F2, top terminal
- Maximum discharge current: 130A (5 seconds)
- Internal resistance: approx. 17 mΩ
- Weight: approx. 2.56 kg (5.64 lb)
- Operating temperature: discharge -15°C to 50°C, charge -15°C to 40°C

FAQs

Q: What is the voltage and capacity of this battery?
A: It is a 12V, 9Ah sealed VRLA lead-acid battery rated at 34W per cell at the 15-minute rate.

Q: What terminal type does it use?
A: It has F2 top terminals, so confirm your existing UPS battery uses the same terminal style before replacing.

Q: Is it equivalent to another Powerware part number?
A: Yes, it is equivalent to the Powerware PWHR1234W2FR.

Q: Will it work with my existing UPS cabling?
A: Yes, it can be installed using existing UPS cabling in compatible Eaton UPS units.

Q: What operating temperatures does it support?
A: Discharge from -15°C to 50°C and charge from -15°C to 40°C.

Q: How long does this battery last in cycle service?
A: It is rated for more than 260 cycles at 100% discharge in cycle service.
