Teltonika TRM500000000/TRM500000300 | TRM500 Industrial 5G Cellular Modem, USB Type-C, PSU Included

Name: Teltonika TRM500000000/TRM500000300 | TRM500 Industrial 5G Cellular Modem, USB Type-C, PSU Included
Brand: Teltonika
SKU: TRM500000000/TRM500000300
Price: 502.21 AUD
Availability: InStock

Authorised Teltonika Partner

SKU:TRM500000000/TRM500000300

In stock:15

$502.21 inc. GST

$456.55 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The TRM500 industrial 5G cellular modem delivers speeds of up to 3.4 Gbps downlink in 5G NSA mode (4x4 MIMO), with backward compatibility for 4G LTE Cat 19 and 3G networks. This variant includes a power supply unit and connects to the host over USB Type-C, which carries network data and power at the same time and can act as a virtual network interface. It suits industrial, remote and fixed-wireless deployments where a compact, rugged modem is needed.

The TRM500 supports both 5G SA and NSA architectures and has four SMA antenna connectors for improved coverage. An anodised aluminium IP30 housing measuring 83 x 25 x 85.4 mm and weighing 94.5 g makes it easy to fit into tight enclosures. It can be mounted on a DIN rail, wall or flat surface using the appropriate additional kit, and drivers support all relevant host platforms.

Features

- Ultra-high 5G speeds of up to 3.4 Gbps
- Supports both SA and NSA 5G architectures
- Backward compatible with 4G Cat 19 and 3G for future-proofing
- USB Type-C carries data and power at the same time and can act as a virtual network interface
- Four SMA antenna connectors for enhanced coverage
- Compact, lightweight industrial design with DIN rail mounting options
- Drivers support all relevant host platforms
- Power supply unit included

Warranty

Teltonika networking products come with a 24-month warranty from the date of purchase. Batteries are covered under a separate 6-month warranty.
https://teltonika-networks.com/support/warranty-repair

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 5G NSA Sub-6GHz: up to 3.4 Gbps DL (4x4 MIMO) / 550 Mbps UL
- 5G SA: 2.4 Gbps DL / 900 Mbps UL
- 4G LTE Cat 19: 1.6 Gbps DL / 200 Mbps UL
- 3G: 42 Mbps DL / 5.76 Mbps UL
- 1 x SIM slot (Mini-SIM)
- 1 x USB Type-C (data and power)
- 4 x SMA antenna connectors for mobile
- Power input: 9-30 VDC (4-pin) or USB Type-C 5 VDC (host must provide 5 V @ 3 A)
- Overvoltage, reverse polarity and surge protection on the 4-pin input
- Power consumption: idle under 5 W, maximum under 12 W
- Reset button: reboot, user default reset and factory reset
- LED indicators: network and power
- IP30 anodised aluminium housing and panels
- Dimensions: 83 x 25 x 85.4 mm
- Weight: 94.5 g
- Mounting: DIN rail, wall mount or flat surface (additional kit required)

FAQs

Q: Does the TRM500 support both 5G SA and NSA networks?
A: Yes. It supports 5G SA at up to 2.4 Gbps downlink and 900 Mbps uplink, and 5G NSA at up to 3.4 Gbps downlink and 550 Mbps uplink.

Q: Does it fall back to 4G or 3G where 5G is unavailable?
A: Yes. The modem is backward compatible with 4G LTE Cat 19 (up to 1.6 Gbps downlink) and 3G (up to 42 Mbps downlink).

Q: How is the TRM500 powered?
A: It can be powered from the 4-pin connector (9-30 VDC) or over USB Type-C at 5 VDC, where the host must provide 5 V at 3 A. This variant includes a power supply unit.

Q: How does the modem connect to my device or router?
A: It connects over USB Type-C, which carries both power and data and can present the modem as a virtual network interface to the host.

Q: How many antennas does it use?
A: It has four SMA connectors for the mobile antennas, which are required for the 4x4 MIMO 5G configuration.

Q: What mounting options are available?
A: The TRM500 can be mounted on a DIN rail, on a wall or on a flat surface. Each option requires an additional mounting kit.
