• Arista compatible SFP-25G-SR-BCC 25GBASE-SR transceiver 850nm 100m MMF LC DOM
1 1

Blue Cable Co

SFP-25G-SR-BCC | Arista Compatible 25GB Multi-Mode 100m (25GBASE-SR)

SFP-25G-SR-BCC | Arista Compatible 25GB Multi-Mode 100m (25GBASE-SR)

SFP-25G-SR-BCC

Stock Status: Enquire

$184.80 AUD
$184.80 AUD
$184.80 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The SFP-25G-SR-BCC is a drop-in compatible replacement for the Arista SFP-25G-SR. This SFP28 transceiver delivers plug-and-play 25 Gigabit Ethernet connectivity over multi-mode fibre in Arista platforms with SFP28 ports. - Compliant with IEEE 802.3by 25GBASE-SR and SFP28 MSA, ensuring interoperability with standards-based 25GbE infrastructure - 850nm VCSEL transmitter, 100m reach over OM4 multi-mode fibre, 70m over OM3 - Dual LC connector, hot-pluggable SFP28 form factor - Digital diagnostics monitoring (DOM) support via SFF-8472 interface for real-time optical power, temperature, and voltage telemetry - Data rate 25.78 Gbps, commercial temperature range 0 to 70 degrees C - Typical power consumption under 1W for high-density deployment

Features

• IEEE 802.3by 25GBASE-SR compliance guarantees interoperability with standards-based 25 Gigabit Ethernet equipment across vendor platforms
• Single-lane 25 Gbps electrical interface using NRZ modulation on the host side, eliminating complex SerDes configurations
• VCSEL (Vertical-Cavity Surface-Emitting Laser) technology at 850nm wavelength optimised for short-reach multi-mode deployments with minimal power dissipation
• SFF-8472 compliant digital diagnostics provide EEPROM-accessible monitoring of Tx/Rx optical power, bias current, module temperature, and supply voltage in real time
• OM3 and OM4 fibre support with typical link budget of 5.3 dB enables flexible cabling in data centre top-of-rack and spine-leaf architectures
• Hot-swappable installation allows zero-downtime insertion and removal in live SFP28 ports without host reboot

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we'll deliver a replacement part before you return the faulty itemminimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: SFP-25G-SR-BCC
Compatible Replacement For: SFP-25G-SR
Compatibility: Arista compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP28
Data Rate: 25.78 Gbps
Wavelength: 850nm (VCSEL)
Fibre Type: Multi-mode (MMF)
Connector Type: Duplex LC
DOM Support: Yes (SFF-8472)
Standards: IEEE 802.3by 25GBASE-SR, SFP28 MSA (SFF-8431, SFF-8432)
Max Reach: 100m over OM4 MMF, 70m over OM3 MMF (per datasheet, subject to fibre and link conditions)
Operating Temperature: 0 to 70 degrees C (commercial)

FAQs

Q: Will this work in place of the Arista SFP-25G-SR?
A: Yes. The SFP-25G-SR-BCC is a direct replacement for the Arista SFP-25G-SR, using the same SFP28 form factor, 25.78 Gbps data rate, and IEEE 802.3by 25GBASE-SR standard. It is plug-and-play compatible with Arista platforms supporting 25GbE SFP28 ports.

Q: Which Arista platforms support this transceiver?
A: This transceiver works in any Arista platform with SFP28 ports supporting 25GBASE-SR, including 7000-series switches. Confirm your specific platform supports SFP28 form factor and 25GbE operation by checking the Arista transceiver and cable compatibility guide for your model.

Q: What fibre types and cable lengths are supported at 25G?
A: At 25.78 Gbps, this module supports up to 100m over OM4 50/125 micron fibre and up to 70m over OM3 50/125 micron fibre. The 850nm VCSEL wavelength is optimised for multi-mode applications. Actual reach depends on fibre quality, loss budget, and connector insertion loss.

Q: Does this module support dual-rate 10G/25G operation?
A: No. The SFP-25G-SR-BCC operates at the native 25GBASE-SR data rate of 25.78 Gbps. It does not support dual-rate 10G/25G operation. For dual-rate applications, consider modules explicitly listed as 10/25G multi-rate or CSR variants.

Q: Can I monitor optical power and module health via the switch CLI?
A: Yes. This transceiver includes SFF-8472 compliant digital diagnostics monitoring (DOM). You can access real-time parameters including transmit and receive optical power (in dBm), bias current, module temperature, and supply voltage through the Arista EOS CLI or SNMP interface.
