Moxa OnCell-G3150A-LTE-EU | OnCell G3150A-LTE Cellular Gateway, Cat 3, EU B1/B3/B7/B8/B20, 0-55C

Authorised Moxa Partner

SKU:OnCell-G3150A-LTE-EU

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa OnCell G3150A-LTE-EU is a rugged industrial LTE Cat 3 cellular gateway that connects serial and Ethernet devices to cellular networks, delivering up to 100 Mbps downlink and 50 Mbps uplink. This EU model supports LTE bands B1/B3/B7/B8/B20 and is rated for standard 0 to 55 C operation, with dual-SIM support for operator backup.

Built for industrial and remote deployments, it combines one 10/100BaseT(X) RJ45 port with a 3-in-1 RS-232/422/485 serial port, redundant dual 12 to 48 VDC power inputs, and a metal IP30 housing for DIN-rail mounting. GuaranLink connectivity, IPsec and OpenVPN support, and hazardous location approvals (ATEX, IECEx) make it suited to secure serial-over-LTE and remote monitoring applications.

Features

- Dual-SIM design for cellular operator backup
- GuaranLink 4-tier reliable cellular connectivity
- Rugged hardware suited to hazardous locations (ATEX Zone 2 / IECEx)
- Secure remote access with IPsec (up to 5 tunnels), GRE and OpenVPN
- Redundant dual power inputs and built-in digital input and alarm contact
- Power isolation design for protection against electrical interference
- Cybersecurity features based on IEC 62443
- 3-in-1 serial port (RS-232/422/485) for serial-over-LTE communication
- Management via web console, SNMPv1/v2c/v3, Telnet, remote SMS control and OnCell Central Manager

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- LTE Cat 3: up to 100 Mbps downlink / 50 Mbps uplink (20 MHz bandwidth)
- EU LTE bands B1 (2100 MHz) / B3 (1800 MHz) / B7 (2600 MHz) / B8 (900 MHz) / B20 (800 MHz)
- Fallback: UMTS/HSPA (42 Mbps DL / 5.76 Mbps UL) and GSM/GPRS/EDGE quad-band
- Dual SIM slots
- 2 x SMA female cellular antenna connectors, 1 x SMA female GPS/GLONASS antenna connector
- 1 x 10/100BaseT(X) RJ45 port
- 1 x RS-232/422/485 serial port, DB9 female, 75 bps to 921.6 kbps
- RS-232 (RJ45) console port
- 1 alarm contact channel and digital input
- Redundant dual 12 to 48 VDC power inputs via terminal block, reverse polarity protection
- Operating temperature 0 to 55 C, storage -40 to 85 C, 5 to 95% non-condensing humidity
- Metal IP30 housing, 126 x 30 x 107.5 mm, 492 g
- DIN-rail mounting, wall mounting with optional kit
- Safety and approvals: UL 60950-1, ATEX, IECEx, EN 61000-6-2/-6-4, EN 301 511
- MTBF 528,596 hrs (Telcordia SR332)
- Package: gateway, DIN-rail kit, 2 x LTE antennas, quick installation guide

FAQs

Q: Which LTE bands does the OnCell G3150A-LTE-EU support?
A: The EU model supports LTE bands B1 (2100 MHz), B3 (1800 MHz), B7 (2600 MHz), B8 (900 MHz) and B20 (800 MHz), with UMTS/HSPA and GSM/GPRS/EDGE fallback.

Q: What is the operating temperature range of this model?
A: The standard -EU model operates from 0 to 55 C. It is not the wide-temperature variant.

Q: Can it connect both serial and Ethernet devices?
A: Yes. It provides one 10/100BaseT(X) RJ45 port and one DB9 serial port configurable as RS-232, RS-422 or RS-485 for serial-over-LTE communication.

Q: Does it support dual SIM operator backup?
A: Yes. Two SIM slots allow failover between cellular operators, and GuaranLink helps maintain a reliable connection.

Q: What VPN options are supported?
A: It supports IPsec VPN with up to 5 concurrent tunnels and OpenVPN in client and server modes, plus GRE.

Q: How is the gateway powered and mounted?
A: It accepts redundant dual 12 to 48 VDC inputs through a terminal block and mounts on a DIN rail. A wall-mount kit is available separately.
