Moxa MRC-1002-T | MRC-1002 Remote Connect Gateway, 2x Ethernet, -40 to 75°C

Authorised Moxa Partner

SKU:MRC-1002-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa MRC-1002-T is an industrial Remote Connect Gateway with two 10/100BaseT(X) Ethernet ports, built for secure remote access to machines and field equipment over the Internet through the Moxa Remote Connect platform. This Ethernet-only model has no cellular interface and is the wide-temperature variant, rated for operation from -40 to 75°C, making it suited to harsh industrial cabinets and outdoor enclosures.

It features an embedded firewall with whitelist access control, end-to-end data encryption and auto virtual IP mapping, so engineers can connect through transparent tunnels using their existing software tools without VPN expertise. A metal IP30 housing, DIN-rail mounting, a digital input, a relay output and a 12 to 36 VDC power input make it straightforward to deploy in control panels and machine builds.

Features

- Embedded firewall with whitelist remote access control
- End-to-end data encryption for remote sessions
- Auto virtual IP mapping removes the need for field IP management
- Transparent tunnels work with existing software tools
- Flexible definition of the relationships between remote connections
- Plug and play deployment with no VPN knowledge required
- Machine operators can control access for on-demand maintenance
- Wide operating temperature range of -40 to 75°C

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x 10/100BaseT(X) Ethernet ports (RJ45), one WAN and one LAN
- 1 x USB 2.0 port for key activation and tunnel connectivity
- 1 digital input and 1 relay output (1 A @ 24 VDC)
- Input voltage 12 to 36 VDC via removable 3-contact terminal block
- Input current 0.62 A max @ 12 VDC
- Power consumption 7.44 W
- Metal housing, IP30 protection
- Dimensions 101 x 27 x 128 mm (3.98 x 1.06 x 5.04 in)
- DIN-rail mounting, wall mounting with optional kit
- Operating temperature -40 to 75°C (-40 to 167°F)
- MTBF 954,531 hrs
- Ethernet-only model, no cellular/LTE interface

FAQs

Q: Does the MRC-1002-T support LTE or cellular connections?
A: No. The MRC-1002-T is an Ethernet-only model with no cellular interface. It connects to the Internet through its WAN Ethernet port.

Q: What is the operating temperature range?
A: The -T model is the wide-temperature variant and operates from -40 to 75°C (-40 to 167°F).

Q: How many Ethernet ports does it have and what are they used for?
A: It has two 10/100BaseT(X) RJ45 ports, one WAN port for the uplink and one LAN port for connecting the remote equipment.

Q: How is the MRC-1002-T powered?
A: It runs from a 12 to 36 VDC supply through a removable 3-contact terminal block, drawing up to 0.62 A at 12 VDC (7.44 W).

Q: How can the gateway be mounted?
A: It mounts on a DIN rail as standard, and wall mounting is possible with the optional wall-mount kit.

Q: Does remote access require VPN configuration?
A: No. Deployment is plug and play, with auto virtual IP mapping and transparent tunnels, so VPN knowledge is not required.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
