Moxa MC-1220-LTECat4-AP | MC-1200 Series 4G LTE Cat 4 miniPCIe Module, LE910C4-AP, APAC

Authorised Moxa Partner

SKU:MC-1220-LTECat4-AP

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa MC-1220-LTECat4-AP is a 4G LTE Cat 4 miniPCIe cellular module for the Moxa MC-1200 Series industrial computers. Built around the Telit LE910C4-AP for the Asia-Pacific region, it delivers up to 150 Mbps downlink and 50 Mbps uplink, giving MC-1200 Series deployments a reliable cellular uplink where wired connectivity is limited.

The module installs in the miniPCIe socket of the MC-1200 Series and has an industrial module-level operating temperature range of -40 to +85 C, suiting remote monitoring, edge computing and field automation sites across Australia and the wider APAC region.

Features

- LTE Cat 4 connectivity for MC-1200 Series computers
- Adds a cellular uplink via the miniPCIe socket on the MC-1200 Series
- APAC-region LE910C4-AP module
- Industrial temperature range at module level

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Module: Telit LE910C4-AP
- LTE category: Cat 4 (3GPP Rel. 10)
- Max data speed: 150 Mbps downlink / 50 Mbps uplink
- Form factor: miniPCIe
- Region: Asia-Pacific (APAC)
- Intended for the Moxa MC-1200 Series (MC-1220)
- Module operating temperature: -40 to +85 C
- Certification (LE910Cx family): RCM (Australia)

FAQs

Q: Which Moxa computers is this LTE module designed for?
A: It is a wireless package for the Moxa MC-1200 Series industrial computers, including the MC-1220, and installs in the miniPCIe socket.

Q: What data speeds does the LE910C4-AP support?
A: As an LTE Cat 4 module it supports up to 150 Mbps downlink and 50 Mbps uplink.

Q: Which region is the LE910C4-AP variant intended for?
A: This variant is built for the Asia-Pacific (APAC) region, including Australia.

Q: What temperature range can the module operate in?
A: The Telit LE910C4-AP module is rated for -40 to +85 C at module level. The host MC-1220 computer is rated for -40 to 70 C.

Q: What form factor does this module use?
A: It is a miniPCIe cellular module supplied as a wireless package for the MC-1200 Series.
