Description

The Moxa ioThinx 4533-LX-T is an advanced modular Linux controller built for industrial automation in harsh environments. It is the wide-temperature variant, rated for -40 to 75°C operation, and pairs a dual-core 1 GHz Armv7 Cortex-A7 CPU with 2 GB DDR3L memory, dual 10/100 RJ45 Ethernet ports and a built-in software-selectable RS-232/422/485 serial port. It supports up to 64 I/O modules on a DIN rail.

The controller runs Moxa Industrial Linux 3 (Debian 11, kernel 5.10) with secure boot and TPM 2.0 hardware-based security, and can be programmed in C/C++ and Python. Built-in Azure, AWS and Alibaba Cloud libraries and an OPC UA server library simplify edge and cloud connectivity, while tool-free installation and removal speeds up deployment.

Features

- Wide -40 to 75°C operating temperature
- Supports TPM 2.0 hardware-based security
- Moxa Industrial Linux with secure boot function
- Supports up to 64 I/O modules
- Built-in Azure, AWS and Alibaba Cloud library
- Built-in OPC UA server library
- Programmable in C/C++ and Python
- Tool-free installation and removal

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- CPU: Armv7 Cortex-A7 dual-core 1 GHz
- Memory: 2 GB DDR3L DRAM, 128 kB MRAM
- Storage: 8 GB eMMC (6 GB user), 1 x microSD slot (up to 32 GB)
- Ethernet: 2 x 10/100BaseT(X) RJ45 ports, 1.5 kV magnetic isolation
- Serial: 1 x RS-232/422 or 2 x RS-485-2w, software-selectable, spring-type Euroblock terminal
- Expansion: up to 64 I/O modules (45MR) or up to 5 communication modules (45ML)
- Operating system: Moxa Industrial Linux 3 (Debian 11, kernel 5.10)
- Security: TPM 2.0, AES-256, SHA-256, SSHv2
- Programming: C/C++, Python
- Power input: 12 to 48 VDC, 1940 mA @ 12 VDC
- Operating temperature: -40 to 75°C (-40 to 167°F)
- Weight: 207.7 g (0.457 lb)
- Mounting: DIN rail

FAQs

Q: What operating temperature range does the ioThinx 4533-LX-T support?
A: The 4533-LX-T is the wide-temperature model and operates from -40 to 75°C (-40 to 167°F).

Q: How many I/O modules can this controller support?
A: It supports up to 64 ioThinx 45MR I/O modules, or up to 5 ioThinx 45ML communication modules.

Q: What operating system and programming languages does it use?
A: It runs Moxa Industrial Linux 3 (Debian 11, kernel 5.10) and can be programmed in C/C++ and Python.

Q: What serial interfaces are available?
A: One software-selectable serial port configured as either RS-232/422 or 2 x RS-485-2w, using a spring-type Euroblock terminal.

Q: What security features are built in?
A: The controller includes TPM 2.0 hardware-based security, secure boot, AES-256 and SHA-256 encryption, and SSHv2.

Q: What power supply does it require?
A: It uses a single 12 to 48 VDC input through a spring-type Euroblock terminal, with over-current and over-voltage protection.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
