Moxa ioPAC 8600-BM009-T | ioPAC 8600 9-Slot Rugged Modular Controller Backplane, -40 to 75°C

Authorised Moxa Partner

SKU:ioPAC 8600-BM009-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The ioPAC 8600-BM009-T is a 9-slot rugged modular controller backplane for the Moxa ioPAC 8600 Series. It accepts CPU, power and I/O modules in a metal housing, and its -40 to 75°C operating range suits harsh industrial automation, rail and field deployments. The 9 slots give you room to build a flexible, expandable controller in a single chassis.

The backplane supports both 85M and 86M series I/O modules with hot-swappable module support. It works with the ioPAC 8600 platform, which supports C/C++ and IEC 61131-3 programming, and carries rail and industrial certifications including EN 50121-4 and EN 50155 for demanding installations.

Features

- Supports both 85M and 86M series I/O modules
- Hot-swappable modules
- Supports C/C++ and IEC 61131-3 programming on the ioPAC 8600 platform
- Rail-level surge and ESD protection
- Wide-temperature -40 to 75°C operation

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 9 module slots
- Metal housing
- Dimensions: 324.8 x 133.35 x 100 mm
- Weight: 3,690 g
- Wall mounting (with optional kit)
- Operating temperature: -40 to 75°C
- Storage temperature: -40 to 85°C
- Ambient relative humidity: 5 to 95% (non-condensing)
- Altitude: up to 2000 m
- Standards: EN 55032/35, EN 61000-6-2/-6-4, FCC Part 15B Class A, EN 50121-4, EN 50155, UL 508, IEC 60068-2-27 (shock), IEC 60068-2-6 (vibration)
- MTBF: 1,350,621 hrs (Telcordia SR-332)

FAQs

Q: How many modules can the ioPAC 8600-BM009-T hold?
A: It provides 9 module slots for CPU, power and I/O modules in the ioPAC 8600 platform.

Q: Which I/O modules are compatible with this backplane?
A: It supports both 85M and 86M series I/O modules.

Q: What operating temperature range does it support?
A: The operating range is -40 to 75°C, with a storage range of -40 to 85°C.

Q: Are the modules hot-swappable?
A: Yes, the backplane supports hot-swappable modules.

Q: Which programming languages are supported on the platform?
A: The ioPAC 8600 platform supports C/C++ and IEC 61131-3 programming.

Q: Does it carry rail certifications?
A: Yes, it is certified to EN 50121-4 and EN 50155, along with other industrial standards such as UL 508.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
