Moxa ioLogik E2214 | Remote I/O Controller, 6 DI, 6 Relay

Authorised Moxa Partner

SKU:ioLogik E2214

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa ioLogik E2214 is a smart Ethernet remote I/O controller with 6 digital inputs and 6 Form A power relay outputs, built for industrial monitoring and control in -10 to 60°C environments. Click&Go control logic supports up to 24 rules, allowing PC-free, event-driven alarms and local control, while the unit reports by exception over SNMP, Modbus TCP and MX-AOPC UA Server.

The digital inputs accept dry or wet contact sensors (NPN or PNP) and can operate as standard DI or as event counters up to 900 Hz. The relay outputs can be used as standard relays or pulse outputs. A 10/100BaseT(X) Ethernet port and an RS-485 port acting as a Modbus RTU Master suit it to integrating existing serial devices. It mounts on a DIN-rail or wall and runs from 12 to 36 VDC.

Features

- Front-end intelligence with Click&Go control logic, up to 24 rules
- Active communication with MX-AOPC UA Server
- Peer-to-peer communications save time and wiring costs
- SNMP v1/v2c/v3 support
- Configuration via web browser or ioAdmin Windows utility
- MXIO library for Windows or Linux simplifies I/O management
- RS-485 Modbus RTU Master port for serial device integration
- Relay outputs usable in relay or pulse output mode
- Digital inputs usable as DI or event counter

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x digital inputs, dry contact or wet contact (NPN or PNP)
- 6 x Form A (N.O.) power relay channels
- Relay rating: 5 A resistive or 2 A inductive at 30 VDC, 250 VAC, 110 VAC
- 1 x 10/100BaseT(X) Ethernet port (RJ45) with 1.5 kV magnetic isolation
- 1 x RS-485 serial port, Modbus RTU Master, 1200 to 115200 bps
- Click&Go control logic, up to 24 rules
- Protocols: Modbus TCP Server (Slave), SNMPv1/v2c/v3, SNMPv1 Trap, Moxa AOPC, CGI commands
- DI counter frequency: 900 Hz, DI points per COM: 3 channels
- Isolation: 3k VDC or 2k Vrms
- Power input: 12 to 36 VDC, 170 mA at 24 VDC
- Real-time clock with battery backup
- Operating temperature: -10 to 60°C (14 to 140°F)
- Dimensions: 115 x 79 x 45.6 mm, weight 250 g
- DIN-rail or wall mounting
- Safety: UL 508
- MTBF: 307,329 hrs (Telcordia SR332)

FAQs

Q: How many inputs and outputs does the ioLogik E2214 provide?
A: It provides 6 digital inputs and 6 Form A (N.O.) power relay outputs.

Q: Can the E2214 operate without a PC or PLC?
A: Yes. Click&Go control logic supports up to 24 rules, so the unit can run event-driven alarms and control locally without a PC.

Q: Which protocols does the ioLogik E2214 support?
A: It supports Modbus TCP Server (Slave), SNMPv1/v2c/v3, SNMPv1 Trap, Moxa AOPC (Active Tag), MX-AOPC UA Server, MXIO library and CGI commands.

Q: What sensor types can the digital inputs connect to?
A: The inputs accept dry contact and wet contact sensors, NPN or PNP, and can operate as standard DI or event counters up to 900 Hz.

Q: What are the relay contact ratings?
A: Contacts are rated 5 A for resistive loads and 2 A for inductive loads at 30 VDC, 250 VAC or 110 VAC.

Q: What is the operating temperature range and how is it powered?
A: This model operates from -10 to 60°C on a 12 to 36 VDC input. A separate wide-temperature -T variant covers -40 to 75°C.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
