Moxa ioLogik E2214-T | ioLogik E2200 Ethernet Remote I/O, 6 DI, 6 Relay, -40 to 75°C

Authorised Moxa Partner

SKU:ioLogik E2214-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The ioLogik E2214-T is a rugged smart Ethernet remote I/O unit with 6 digital inputs and 6 relay outputs, built for industrial automation and monitoring. As a wide-temperature -T model it operates from -40 to 75°C, making it suited to outdoor cabinets, factory floors and other harsh environments where standard I/O would struggle.

As an active I/O controller it uses Click&Go front-end control logic to run local rules without a central controller, and it can send active messages by SNMP trap, TCP or email. It connects over 10/100 Mbps Ethernet with a single RS-485 serial port, supports Modbus/TCP, and works with MX-AOPC UA Server and MXIO software.

Features

- Front-end intelligence with Click&Go control logic, up to 24 rules
- Active communication with MX-AOPC UA Server
- Active messaging via SNMP trap, TCP and email
- Supports SNMPv1, v2c and v3
- I/O peer-to-peer function
- Wide-temperature -T model for harsh environments

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x digital inputs
- 6 x relay outputs
- No analog input/output, RTD or thermocouple inputs
- 1 x 10/100 Mbps RJ-45 Ethernet port
- 1 x RS-485 serial port (terminal connection)
- Power input: 12 to 36 VDC
- Operating temperature: -40 to 75°C
- Storage temperature: -40 to 85°C
- Operating humidity: 5 to 95% non-condensing
- Protocols: Modbus/TCP (Slave), TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
- Compatible software: MX-AOPC UA Server, MXIO
- Safety: UL 508
- EMC: EN 61000-6-2/6-4, CISPR 22, FCC Part 15B Class A
- ESD (IEC 61000-4-2): Contact 4 kV, Air 8 kV
- Compliance: RoHS, CRoHS, WEEE

FAQs

Q: What does the -T suffix mean on the ioLogik E2214-T?
A: The -T denotes the wide-temperature model, rated for operation from -40 to 75°C, suited to harsh industrial environments.

Q: How many inputs and outputs does the ioLogik E2214-T provide?
A: It provides 6 digital inputs and 6 relay outputs. It has no analog input or output channels.

Q: Can the ioLogik E2214-T operate without a central controller?
A: Yes. Its Click&Go front-end control logic supports up to 24 rules, so it can act on I/O events locally and send alerts by SNMP trap, TCP or email.

Q: What network and serial connections does it have?
A: It has one 10/100 Mbps RJ-45 Ethernet port and one RS-485 serial port via terminal connection.

Q: What power supply does the ioLogik E2214-T require?
A: It accepts a 12 to 36 VDC power input.

Q: Which software and protocols does it work with?
A: It supports Modbus/TCP (Slave), SNMP, HTTP, SMTP and other standard protocols, and works with MX-AOPC UA Server and MXIO software.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
