Moxa ioLogik E2212 | ioLogik E2200 Ethernet Remote I/O, 8 DI, 8 DO, 4 DIO

Authorised Moxa Partner

SKU:ioLogik E2212

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa ioLogik E2212 is an Ethernet remote I/O unit with 8 digital inputs, 8 digital outputs and 4 software-configurable DIO channels, rated for -10 to 60°C operation. It suits factory and building automation where field signals need to be brought onto an Ethernet network over Modbus/TCP, with Click&Go front-end control logic handling up to 24 rules locally.

The unit includes a 10/100 Mbps RJ45 Ethernet port and an RS-485-2w serial port for Modbus/RTU. It supports active messaging to MX-AOPC UA Server, smart alarm management via email, SNMP Trap, TCP and UDP, and browser-based configuration. The MXIO library for Windows and Linux simplifies integration, and DIN-rail or wall mounting keeps installation flexible.

Features

- Front-end intelligence with patented Click&Go control logic, up to 24 rules
- Active communication with MX-AOPC UA Server
- Smart alarm management via email, SNMP Trap, TCP and UDP
- SNMP v1/v2c/v3 support
- Configuration via web browser
- MXIO library for Windows and Linux simplifies I/O management
- Modbus/TCP and Modbus/RTU support
- DO over-voltage, over-current and over-temperature protection

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x digital inputs, dry or wet contact (NPN or PNP), 3k VDC isolation
- 8 x digital outputs, sink type, 200 mA per channel
- 4 x DIO channels, software configurable
- DI counter frequency 900 Hz, DO pulse output frequency 1 kHz
- 1 x 10/100 Mbps RJ45 Ethernet port with 1.5 kV magnetic isolation
- 1 x RS-485-2w serial port, 1200 to 115200 bps, Modbus/RTU
- Protocols: Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
- Power input 12 to 36 VDC, 136 mA @ 24 VDC
- Screw-fastened Euroblock terminal connectors
- Operating temperature -10 to 60°C, 5 to 95% non-condensing humidity
- Dimensions 115 x 79 x 45.6 mm, weight 250 g
- DIN-rail or wall mounting, plastic housing
- Safety UL 508, EMC EN 61000-6-2/-6-4, FCC Part 15B Class A

FAQs

Q: How many I/O channels does the ioLogik E2212 provide?
A: It provides 8 digital inputs, 8 digital outputs and 4 DIO channels that can be configured as inputs or outputs in software.

Q: What operating temperature range does this model support?
A: This standard model operates from -10 to 60°C. A separate wide-temperature -T model is available for -40 to 75°C environments.

Q: Which communication protocols are supported?
A: It supports Modbus/TCP over Ethernet, Modbus/RTU over RS-485-2w, plus TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP and SMTP.

Q: What type of digital inputs and outputs does it use?
A: Digital inputs accept dry contact and wet contact sensors (NPN or PNP) and can work as DI or event counters. Outputs are sink type and can work as DO or pulse outputs.

Q: How is the ioLogik E2212 powered and mounted?
A: It runs on 12 to 36 VDC (24 VDC nominal) and mounts on a DIN rail or directly to a wall.

Q: Can it run local control logic without a PLC?
A: Yes. Click&Go front-end control logic supports up to 24 rules on the unit, and it can send alarms by email, SNMP Trap, TCP or UDP.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
