Moxa ANT-WSB-AHRM-05-1.5m | 2.4 GHz 5 dBi Omnidirectional Indoor Antenna, RP-SMA Male, 1.5m Cable

Authorised Moxa Partner

SKU:ANT-WSB-AHRM-05-1.5m

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa ANT-WSB-AHRM-05-1.5m is a 2.4 GHz omnidirectional indoor WLAN antenna with 5 dBi gain, an RP-SMA male connector and an attached 1.5m cable. Its compact rubber-duck design suits wireless access points, clients and gateways that need a simple range upgrade over a stock antenna in indoor industrial and commercial environments.

The antenna can be mounted straight onto the device or placed on its magnetic base, giving flexible positioning for better signal coverage. With a 50 ohm impedance, linear polarisation and a 360 degree horizontal beamwidth, it integrates easily with Moxa wireless products and other 2.4 GHz equipment that uses an RP-SMA connection.

Features

- High gain 5 dBi antenna for improved 2.4 GHz coverage
- Small size for easy installation
- Lightweight for portable deployment
- Straight mount or magnetic base mount
- RP-SMA male connector
- 1.5m RG-174 cable for flexible placement

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Frequency: 2.4 to 2.5 GHz
- Antenna type: Omni-directional, rubber antenna
- Typical gain: 5 dBi
- Connector: RP-SMA (male)
- Impedance: 50 ohms
- Polarisation: Linear
- HPBW: 360 degrees horizontal / 80 degrees vertical
- VSWR: 2:1 max
- Cable: RG-174, 1.5 m
- Length (including base): 236 mm (9.29 in)
- Weight: 300 g (0.66 lb)
- Radome: black plastic
- Installation: magnetic mount
- Operating temperature: -40 to 80°C (-40 to 176°F)
- Storage temperature: -40 to 80°C (-40 to 176°F)
- Ambient relative humidity: 5 to 95% (non-condensing)

FAQs

Q: What frequency band does this antenna support?
A: It operates in the 2.4 to 2.5 GHz band, suitable for 2.4 GHz WLAN equipment.

Q: What connector does it use?
A: It uses an RP-SMA male connector, so confirm your device has a matching RP-SMA female port.

Q: Is this antenna suitable for outdoor use?
A: No, it is designed for indoor installation.

Q: How is the antenna mounted?
A: It can be installed straight onto the device or placed on its magnetic base, with a 1.5m cable linking it to the equipment.

Q: What is the antenna gain and radiation pattern?
A: Typical gain is 5 dBi with an omnidirectional pattern, covering 360 degrees horizontally and 80 degrees vertically.

Q: What temperatures can it operate in?
A: The operating temperature range is -40 to 80°C, with humidity of 5 to 95% non-condensing.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
