Moxa 86M-2604D-T | ioPAC 8600 6-Relay Output I/O Module, Form A (N.O.), -40 to 75°C

Authorised Moxa Partner

SKU:86M-2604D-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa 86M-2604D-T is a rugged relay output I/O module for the ioPAC 8600 Series modular programmable controllers. It provides 6 Form A (N.O.) power relay channels with channel LED indicators, and supports relay or PWM I/O modes. Contacts are rated at 5 A at 30 VDC or 250 VAC resistive load, making it suited to switching field devices in industrial automation, rail and other harsh environments.

Built for an operating temperature range of -40 to 75°C, this module expands the output capacity of ioPAC 8600 controllers using spring-type Euroblock terminals for fast, reliable field wiring. It offers channel-to-channel isolation and complies with the mandatory test items of EN 50121-4 and EN 50155, so it can be deployed where reliability under heat, cold and vibration is essential.

Features

- Rugged, compact design for harsh environments
- Wide operating temperature range of -40 to 75°C
- Complies with EN 50121-4 and EN 50155 mandatory test items
- Channel-to-channel isolation
- Expands the I/O capabilities of ioPAC 8600 Series controllers
- Spring-type Euroblock terminals for quick field wiring

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 6 x relay channels, Form A (N.O.) power relay
- I/O mode: relay or PWM
- Contact rating (resistive load): 5 A @ 30 VDC, 250 VAC
- Contact resistance: 100 milli-ohms (max.)
- Electrical endurance: 60,000 operations @ 5 A resistive load
- Mechanical endurance: 5,000,000 operations
- Pulse output frequency: 0.33 Hz at rated load
- Relay on/off time: 10 ms (max.)
- Isolation: 3k VDC or 2k Vrms (to system)
- Connector: spring-type Euroblock terminal
- Channel LED indicators
- Power consumption: 127 mA @ 24 VDC
- Operating temperature: -40 to 75°C (-40 to 167°F)
- Storage temperature: -40 to 85°C (-40 to 185°F)
- Ambient relative humidity: 5 to 95% (non-condensing)
- MTBF: 4,173,843 hrs (Telcordia SR332)

FAQs

Q: What type of relays does the Moxa 86M-2604D-T provide?
A: It provides 6 Form A (N.O.) power relay channels, each with a channel LED indicator.

Q: What is the contact rating of the relay outputs?
A: Each contact is rated at 5 A at 30 VDC or 250 VAC with a resistive load.

Q: Which controllers is this module designed for?
A: It is a module for the Moxa ioPAC 8600 Series modular programmable controllers, where it expands the output capacity.

Q: What operating temperature range does it support?
A: It operates from -40 to 75°C (-40 to 167°F), suited to harsh industrial and rail environments.

Q: Does the module support railway standards?
A: Yes, it complies with the mandatory test items of EN 50121-4 and EN 50155.

Q: How is field wiring connected to the module?
A: Field wiring connects through spring-type Euroblock terminals.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
