Moxa 65M-BMIO04-CT-T | ioPAC 6500 4-Slot I/O Backplane, Conformal Coated, -40 to 75°C

Authorised Moxa Partner

SKU:65M-BMIO04-CT-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa 65M-BMIO04-CT-T is a 4-slot I/O backplane module for the modular ioPAC 6500 Linux-based RTU and IIN controller platform. It provides four slots for I/O modules, is conformal coated for protection in harsh environments, and is rated for operation from -40 to 75°C, making it suited to utility, transport and industrial automation cabinets.

The backplane is part of the fully modular ioPAC 6500 system, which pairs an Arm Cortex-A53 quad-core CPU with a built-in Layer-2 managed switch. Tool-free installation and a hot-swappable design simplify deployment and maintenance, and a 2 x 2 pin grid prevents erroneous installation when assembling the stack.

Features

- Tool-free hardware installation
- Hot-swappable design
- Fully modular, Lego-like mechanical design for flexible deployment
- 2 x 2 pin grid design prevents erroneous installation (assembly order PWR > COM > CPU > EXP > IO)
- Conformal coated for protection in harsh environments
- Part of the ioPAC 6500 platform with Arm Cortex-A53 quad-core CPU and built-in Layer-2 managed switch

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 slots for I/O modules
- Conformal coating: Yes
- Operating temperature: -40 to 75°C
- Power consumption: 0.117 A @ 12 VDC
- Dimensions: 172 x 177 x 45.5 mm (6.77 x 6.97 x 1.79 in)
- Weight: 395 g (0.87 lb)
- MTBF: 6,124,471 hrs

FAQs

Q: How many I/O modules does the 65M-BMIO04-CT-T support?
A: This backplane provides 4 slots for I/O modules.

Q: What temperature range is this backplane rated for?
A: It is rated for operation from -40 to 75°C and is conformal coated for harsh environments.

Q: Which Moxa controllers is this backplane designed for?
A: It is part of the modular ioPAC 6500 Series (65M) platform of Linux-based RTU and IIN controllers.

Q: Does it support hot swapping?
A: Yes. The ioPAC 6500 design supports tool-free installation and hot-swappable modules.

Q: In what order are ioPAC 6500 modules assembled?
A: The assembly order is PWR, COM, CPU, EXP, then IO. The 2 x 2 pin grid design prevents erroneous installation.

Q: What are the dimensions and weight?
A: The backplane measures 172 x 177 x 45.5 mm and weighs 395 g.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
