MMA1B00-B150D-BCC | NVIDIA Mellanox Compatible 40GB Multi-Mode QSFP+ 150m (40GBASE-SR4)

The MMA1B00-B150D-BCC is a Blue Cable Co 40GbE 40GBASE-SR4 multi-mode QSFP+ optical transceiver, compatible with NVIDIA Mellanox platforms. Operating at 850nm across four parallel channels via an MPO connector, it supports up to 150m on OM4 fibre and up to 100m on OM3 fibre at 40Gb/s. This plug-and-play module includes digital diagnostic monitoring (DDM) covering temperature, voltage, and optical power levels, and is tested in our state-of-the-art lab in Sydney, Australia to ensure NVIDIA Mellanox platform compatibility. Stocked and shipped from Sydney, Australia, and backed by Blue Cable Co's 5-year advanced hardware replacement warranty.

• Plug-and-play QSFP+ form factor — no additional configuration required
• IEEE 802.3 40GBASE-SR4 compliant, 40Gb/s via 4x10.3125Gb/s parallel channels
• 850nm VCSEL transmitter over parallel multi-mode fibre with MPO connector
• Up to 150m on OM4 MMF; up to 100m on OM3 MMF (per datasheet, depends on fibre and link conditions)
• Digital diagnostic monitoring (DDM) — covers supply voltage, temperature, Tx/Rx optical power, and VCSEL bias
• Hot-pluggable QSFP+ design for live insertion without system downtime
• Operating case temperature range: 0°C to +70°C
• Power dissipation: 1.3W typical, 1.5W maximum
• RoHS compliant and Class 1 laser safe
• Tested in Blue Cable Co's Sydney lab for NVIDIA Mellanox platform compatibility
• Stocked in Sydney, Australia for fast local dispatch
• Backed by Blue Cable Co's 5-year advanced hardware replacement warranty

- NVIDIA Mellanox compatible 40GbE multi-mode QSFP+ optical transceiver
- Plug-and-play — installs in seconds with no configuration required
- IEEE 802.3 40GBASE-SR4 compliant, 40Gb/s across 4 parallel channels
- 850nm VCSEL transmitter with MPO connector for parallel MMF cabling
- Up to 150m on OM4 MMF; up to 100m on OM3 MMF
- DDM covering temperature, voltage, Tx/Rx optical power, and VCSEL bias
- Hot-pluggable QSFP+ footprint for live insertion
- Operating case temperature 0°C to +70°C, 1.5W maximum power
- RoHS compliant and Class 1 laser safe
- Tested in Blue Cable Co's Sydney lab for NVIDIA Mellanox platform compatibility
- Stocked in Sydney, Australia for fast local dispatch
- 5-year advanced hardware replacement warranty from Blue Cable Co

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.
