• Silver metallic mcl3208011-sx-bcc sfp transceiver module with blue cable co label for 1gb multi-mode 550m use
1 1

Blue Cable Co

MC3208011-SX-BCC | NVIDIA Mellanox Compatible 1GB Multi-Mode SFP 550m (1000BASE-SX)

MC3208011-SX-BCC | NVIDIA Mellanox Compatible 1GB Multi-Mode SFP 550m (1000BASE-SX)

MC3208011-SX-BCC

In stock:30

$49.50 AUD
$49.50 AUD
$49.50 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The MC3208011-SX-BCC is a Blue Cable Co 1GbE multi-mode SFP optical transceiver, compatible with NVIDIA Mellanox platforms. Using an 850nm VCSEL laser transmitter and duplex LC connector, it supports reaches of up to 550m on 50/125um MMF or up to 300m on 62.5/125um MMF. This plug-and-play module is tested in our state-of-the-art lab in Sydney, Australia to verify NVIDIA Mellanox platform compatibility, and is backed by Blue Cable Co's 5-year advanced hardware replacement warranty.

  • Plug-and-play SFP form factor — no additional configuration required
  • 850nm oxide VCSEL laser transmitter for reliable short-range multi-mode operation
  • Up to 550m reach on 50/125um MMF, up to 300m on 62.5/125um MMF (per datasheet, depends on fibre and link conditions)
  • Duplex LC connector for standard multi-mode fibre patch leads
  • Hot-pluggable design for live insertion without system downtime
  • Operating case temperature range: -20°C to +85°C
  • Single 3.3V power supply, low power dissipation
  • RoHS compliant and lead free
  • Tested in Blue Cable Co's Sydney lab for NVIDIA Mellanox platform compatibility
  • Backed by Blue Cable Co's 5-year advanced hardware replacement warranty

Features

- NVIDIA Mellanox compatible 1GbE multi-mode SFP optical transceiver
- Plug-and-play — installs in seconds with no configuration required
- 850nm VCSEL laser transmitter with duplex LC connector
- Up to 550m reach on 50/125um MMF; up to 300m on 62.5/125um MMF
- Hot-pluggable SFP footprint for live insertion
- Wide operating case temperature range: -20°C to +85°C
- Single 3.3V supply with low power dissipation
- RoHS compliant and lead free construction
- Tested in Blue Cable Co's Sydney lab for NVIDIA Mellanox platform compatibility
- 5-year advanced hardware replacement warranty from Blue Cable Co

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: MC3208011-SX-BCC
Reference SKU: MC3208011-SX
Compatibility: NVIDIA Mellanox compatible
Form Factor: SFP
Data Rate: Up to 1.25 Gb/s (supports 1.062, 1.25, and 2.125 Gb/s)
Wavelength: 850nm
Transmitter Type: Oxide VCSEL
Fibre Type: Multi-Mode
Connector Type: LC (Duplex)
Max Reach (50/125um MMF): Up to 550m (per datasheet, depends on fibre and link conditions)
Max Reach (62.5/125um MMF): Up to 300m (per datasheet, depends on fibre and link conditions)
Operating Case Temperature: -20°C to +85°C
Storage Temperature: -40°C to +85°C
Power Supply: 3.3V
RoHS Compliant: Yes
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Lab Testing: Tested in Sydney, Australia

FAQs

Q1: Which platforms is the MC3208011-SX-BCC compatible with?
A1: This transceiver is compatible with NVIDIA Mellanox platforms that support SFP form factor optical modules. It is designed as a direct compatible replacement for the OEM MC3208011-SX. If you need to confirm fit for a specific switch or NIC model, contact our team before ordering.

Q2: How was this transceiver tested for compatibility?
A2: Each MC3208011-SX-BCC unit is tested in Blue Cable Co's state-of-the-art lab in Sydney, Australia against the target NVIDIA Mellanox platform to verify compatibility before it is sold.

Q3: What fibre type and maximum reach does this module support?
A3: The MC3208011-SX-BCC supports up to 550m on 50/125um multi-mode fibre and up to 300m on 62.5/125um multi-mode fibre, per the NVIDIA Mellanox datasheet. Actual reach depends on fibre quality and link conditions.

Q4: Is this a plug-and-play module, or is additional configuration needed?
A4: It is plug-and-play. Insert the module into a compatible SFP port and your system should recognise it immediately. No additional configuration or software is required for standard operation.

Q5: What warranty does this product carry?
A5: The MC3208011-SX-BCC is covered by Blue Cable Co's 5-year advanced hardware replacement warranty. This is a Blue Cable Co warranty and is separate from any OEM warranty terms.
