MC2210511-LR4-BCC | NVIDIA Mellanox Compatible 40GB Single-Mode QSFP+ 10km (40GBASE-LR4)

The MC2210511-LR4-BCC is a Blue Cable Co 40GbE 40GBASE-LR4 single-mode QSFP+ optical transceiver, compatible with NVIDIA Mellanox platforms. Using four CWDM DFB laser channels multiplexed over a duplex LC connection at 1310nm, it supports link lengths of up to 10km on single-mode fibre — making it a strong fit for inter-building and campus-scale 40G deployments. This plug-and-play module includes digital diagnostic monitoring (DDM) and is tested in our state-of-the-art lab in Sydney, Australia to ensure NVIDIA Mellanox platform compatibility. Stocked and shipped from Sydney, Australia, and backed by Blue Cable Co's 5-year advanced hardware replacement warranty.

• Plug-and-play QSFP+ form factor — no additional configuration required
• IEEE 802.3ba 40GBASE-LR4 compliant, up to 40Gb/s over four CWDM channels
• 1310nm CWDM DFB laser transmitters with high-sensitivity PIN receivers
• Single-mode fibre with duplex LC connector — no MPO cabling required
• Maximum link length of 10km (per datasheet, depends on fibre and link conditions)
• Digital diagnostic monitoring (DDM) via SFF-8636 compliant I2C management interface
• Hot-pluggable QSFP+ design for live insertion without system downtime
• Operating case temperature range: 0°C to +70°C
• Power consumption: 2.8W typical (up to 3.5W depending on variant supplied)
• RoHS compliant and Class 1 laser safe
• Tested in Blue Cable Co's Sydney lab for NVIDIA Mellanox platform compatibility
• Stocked in Sydney, Australia for fast local dispatch
• Backed by Blue Cable Co's 5-year advanced hardware replacement warranty

- NVIDIA Mellanox compatible 40GbE single-mode QSFP+ optical transceiver
- Plug-and-play — installs in seconds with no configuration required
- IEEE 802.3ba 40GBASE-LR4 compliant, up to 40Gb/s over four CWDM channels
- 1310nm CWDM DFB laser transmitters over duplex LC — no MPO cabling required
- Maximum link length of 10km on single-mode fibre
- DDM via SFF-8636 compliant I2C management interface
- Hot-pluggable QSFP+ footprint for live insertion
- Operating case temperature 0°C to +70°C
- RoHS compliant and Class 1 laser safe
- Tested in Blue Cable Co's Sydney lab for NVIDIA Mellanox platform compatibility
- Stocked in Sydney, Australia for fast local dispatch
- 5-year advanced hardware replacement warranty from Blue Cable Co
