Juniper SFP-GE40KT13R15 | 1G BiDi SFP Transceiver, UPLINK, Tx1310/Rx1550nm, SMF, 40km, LC

Name: Juniper SFP-GE40KT13R15 | 1G BiDi SFP Transceiver, UPLINK, Tx1310/Rx1550nm, SMF, 40km, LC
Brand: Juniper
SKU: SFP-GE40KT13R15
Price: 747.18 AUD
Availability: BackOrder

Authorised Juniper Partner

SKU:SFP-GE40KT13R15

Stock Status: Enquire

$747.18 inc. GST

$679.25 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Juniper SFP-GE40KT13R15 is a 1000BASE-BX Gigabit Ethernet BiDi SFP transceiver designed for UPLINK applications over a single strand of single-mode fibre (SMF) at distances up to 40km. Operating with a Tx wavelength of 1310nm and Rx wavelength of 1550nm, it eliminates the need for a second fibre strand — ideal for long-reach enterprise and service provider links where fibre infrastructure is limited. Digital Diagnostics Monitoring (DDM) enables real-time visibility into optical parameters for proactive fault detection.

This transceiver must be paired with the complementary DOWNLINK unit (SFP-GE40KT15R13, Tx1550/Rx1310) to complete a bidirectional link. It is SFP MSA and IEEE 802.3z compliant, and compatible with Juniper MX, M, T, E, and ERX series platforms.

Features

- Bidirectional (BiDi) transmission over a single strand of fibre — halves fibre infrastructure requirements
- Digital Diagnostics Monitoring (DDM) for real-time optical parameter visibility and proactive fault detection
- 40km reach over 9/125 µm single-mode fibre — suitable for long-haul enterprise and service provider links
- LC Simplex connector for straightforward BiDi deployment
- SFP MSA (Multi-Source Agreement) compliant — broad platform interoperability
- IEEE 802.3z compliant for standards-based Gigabit Ethernet operation
- Must be paired with complementary DOWNLINK SFP (SFP-GE40KT15R13, Tx1550nm / Rx1310nm) for a complete link
- Compatible with Juniper MX, M, T, E, and ERX series routers and switches

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Standard: 1000BASE-BX, UPLINK
- Data Rate: 1 Gbps (1000 Mbit/s)
- Form Factor: SFP
- Tx Wavelength: 1310 nm
- Rx Wavelength: 1550 nm
- Fiber Type: Single-Strand Single-Mode Fibre (SMF), 9/125 µm
- Reach: 40 km
- Connector: LC Simplex
- Digital Diagnostics Monitoring (DDM/DOM): Yes
- Operating Temperature: 0°C to 70°C (Standard)
- Complementary DOWNLINK SFP: SFP-GE40KT15R13 (Tx1550nm / Rx1310nm)

FAQs

Q: What is the difference between the SFP-GE40KT13R15 and SFP-GE40KT15R13?
A: The SFP-GE40KT13R15 is the UPLINK transceiver (Tx1310nm / Rx1550nm), while the SFP-GE40KT15R13 is the DOWNLINK unit (Tx1550nm / Rx1310nm). Both must be used together at opposite ends of a single-strand SMF link to complete a bidirectional Gigabit Ethernet connection.

Q: Can this SFP transceiver work with a standard duplex fibre cable?
A: No. This is a BiDi (bidirectional) transceiver that uses a single strand of single-mode fibre with an LC Simplex connector. It is not compatible with duplex (dual-strand) fibre setups.

Q: Which Juniper platforms support the SFP-GE40KT13R15?
A: This transceiver is compatible with Juniper router and switch platforms including the MX, M, T, E, and ERX series. Always verify compatibility with your specific platform and line card before ordering.

Q: Does this transceiver support Digital Diagnostics Monitoring (DDM)?
A: Yes. The SFP-GE40KT13R15 includes DDM (also known as DOM), allowing real-time monitoring of optical parameters such as transmit power, receive power, temperature, and supply voltage directly from the network management system.

Q: What is the maximum reach of this transceiver?
A: This transceiver supports a maximum link distance of 40km over 9/125 µm single-strand single-mode fibre when paired with its complementary DOWNLINK SFP (SFP-GE40KT15R13).

Q: Can I purchase the SFP-GE40KT13R15 in Australia from IP Trading?
A: Yes. IP Trading (iptrading.com.au) supplies Juniper transceivers including the SFP-GE40KT13R15, offering competitive pricing and local Australian support. Contact us for volume pricing or to order the complementary DOWNLINK SFP as a pair.
