Juniper SFP-GE10KT15R13 | 1GbE BiDi SFP Transceiver, SMF, 10km, Tx1550/Rx1310, DOWNLINK

Name: Juniper SFP-GE10KT15R13 | 1GbE BiDi SFP Transceiver, SMF, 10km, Tx1550/Rx1310, DOWNLINK
Brand: Juniper
SKU: SFP-GE10KT15R13
Price: 512.51 AUD
Availability: BackOrder

Authorised Juniper Partner

SKU:SFP-GE10KT15R13

Stock Status: Enquire

$512.51 inc. GST

$465.92 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The SFP-GE10KT15R13 is a Juniper Networks 1000BASE-BX10 DOWNLINK SFP transceiver delivering Gigabit Ethernet over a single strand of single-mode fibre at up to 10 km. Using WDM bidirectional technology, it transmits at 1550 nm and receives at 1310 nm via an LC Simplex connector — halving fibre infrastructure costs by eliminating the need for a second strand. It must be paired with a compatible UPLINK SFP (e.g. SFP-GE10KT13R15) to complete the link.

The module supports Juniper MX, M, T, E, and ERX series platforms and is MSA-compliant for broad interoperability. Digital Diagnostics Monitoring (DDM/DOM) enables real-time visibility into optical power, temperature, and voltage for proactive link management. Rated for standard operating temperatures (0°C to 70°C).

Features

- Bidirectional (BiDi) operation — transmit and receive over a single fibre strand, halving fibre cabling requirements
- WDM technology enables simultaneous Tx at 1550 nm and Rx at 1310 nm on one SMF strand
- Must be paired with a DOWNLINK's counterpart UPLINK SFP (SFP-GE10KT13R15) to complete the fibre link
- Supports Gigabit Ethernet (1000BASE-BX10-D) on Juniper MX, M, T, E, and ERX series platforms
- MSA-compliant for broad multi-vendor interoperability
- Digital Diagnostics Monitoring (DDM/DOM) for real-time monitoring of optical power, temperature, voltage, and bias current
- LC Simplex connector for single-strand SMF (9/125 µm) operation
- Standard operating temperature range: 0°C to 70°C

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form Factor: SFP
- Ethernet Standard: 1000BASE-BX10-D (Gigabit Ethernet)
- Data Rate: 1000 Mbps (1GbE)
- Direction: DOWNLINK
- Transmit Wavelength (Tx): 1550 nm
- Receive Wavelength (Rx): 1310 nm
- Fiber Type: Single-Mode Fiber (SMF), single strand, 9/125 µm
- Maximum Reach: 10 km
- Connector: LC Simplex
- Temperature Range: Standard (0°C to 70°C)
- Digital Diagnostics Monitoring (DDM/DOM): Supported
- Compliance: MSA (Multi-Source Agreement)

FAQs

Q: What is the difference between the SFP-GE10KT15R13 and SFP-GE10KT13R15?
A: The SFP-GE10KT15R13 is the DOWNLINK module (Tx 1550 nm / Rx 1310 nm), while the SFP-GE10KT13R15 is the UPLINK module (Tx 1310 nm / Rx 1550 nm). These two must be paired at opposite ends of a single-mode fibre span to form a complete 1GbE BiDi link.

Q: Can this transceiver operate over a standard dual-strand fibre patch cable?
A: No. The SFP-GE10KT15R13 uses BiDi (WDM) technology and requires only a single strand of single-mode fibre via an LC Simplex connection. Using a dual-strand cable would require an adapter, and only one strand would carry traffic.

Q: Which Juniper platforms is this transceiver compatible with?
A: The SFP-GE10KT15R13 is compatible with Juniper Networks MX, M, T, E, and ERX series routers and switches that support standard SFP ports. It is also MSA-compliant, which may allow use in third-party SFP-compatible equipment.

Q: Does this module support Digital Diagnostics Monitoring (DDM)?
A: Yes, the SFP-GE10KT15R13 supports DDM (also known as DOM), allowing network administrators to monitor real-time optical parameters such as transmit/receive power, temperature, voltage, and bias current directly from the device management interface.

Q: Is this transceiver suitable for outdoor or industrial deployments?
A: The SFP-GE10KT15R13 is rated for standard commercial temperatures (0°C to 70°C) and is best suited for indoor or controlled-environment deployments. For harsh or industrial environments requiring extended temperature ranges, a different variant would be required.

Q: Can I purchase this transceiver in Australia from IP Trading?
A: Yes. The Juniper SFP-GE10KT15R13 is available to order directly from iptrading.com.au. IP Trading is an Australian-owned and operated B2B IT hardware reseller with over two decades of experience supplying networking equipment to Australian businesses.
