Juniper SFP-GE10KT14R13 | 1GbE BiDi SFP Transceiver, SMF, Tx 1490nm/Rx 1310nm, BX10-D, 10km

Name: Juniper SFP-GE10KT14R13 | 1GbE BiDi SFP Transceiver, SMF, Tx 1490nm/Rx 1310nm, BX10-D, 10km
Brand: Juniper
SKU: SFP-GE10KT14R13
Price: 356.26 AUD
Availability: BackOrder

Authorised Juniper Partner

SKU:SFP-GE10KT14R13

Stock Status: Enquire

$356.26 inc. GST

$323.87 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The SFP-GE10KT14R13 is a 1000BASE-BX10-D Gigabit Ethernet BiDi SFP transceiver designed for single-mode fibre deployments over a single LC simplex strand at up to 10 km. Operating as the Downlink variant with Tx at 1490 nm and Rx at 1310 nm, it must be paired with a compatible BX10-U Uplink SFP (such as the SFP-GE10KT13R14) to complete a bidirectional link — eliminating the need for a second fibre strand and reducing cabling infrastructure costs. Digital Diagnostics Monitoring (DDM) enables real-time visibility into transceiver performance, including optical power, temperature, and voltage.

Compliant with IEEE 802.3-2005 and compatible with Juniper M Series, MX Series, T Series routers and EX Series switches, this SFP integrates seamlessly into existing Juniper network environments. Standard operating temperature (0°C to 70°C) suits typical enterprise and data centre deployments.

Features

- Bidirectional (BiDi) operation — single fibre strand carries both Tx (1490 nm) and Rx (1310 nm) traffic
- 1000BASE-BX10 Downlink standard — pairs with BX10-U SFP (SFP-GE10KT13R14) at the remote end
- Digital Diagnostics Monitoring (DDM) for real-time transceiver health and performance visibility
- IEEE 802.3-2005 compliant for broad interoperability
- Single-mode fibre (SMF) 9/125 µm with Simplex LC connector — reduces cabling infrastructure costs
- Compatible with Juniper M Series, MX Series, T Series routers and EX Series switches
- Standard operating temperature range (0°C to 70°C) for enterprise and data centre environments

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Data Rate: 1000 Mbps (1GbE)
- Standard: 1000BASE-BX10-D (Downlink)
- Form Factor: SFP
- Connector: Simplex LC (single strand SMF)
- Transmit Wavelength: 1490 nm (1480–1500 nm range)
- Receive Wavelength: 1310 nm
- Fiber Type: Single-Mode Fiber (SMF) 9/125 µm
- Maximum Reach: 10 km
- Average Launch Power: –9 to –3 dBm
- Average Receive Power: –19.5 to –3 dBm
- Receiver Saturation: –3 dBm
- Digital Diagnostics Monitoring (DDM): Yes
- IEEE Standard: 802.3-2005
- Operating Temperature: 0°C to 70°C (Standard)

FAQs

Q: What is the difference between the SFP-GE10KT14R13 and SFP-GE10KT13R14?
A: The SFP-GE10KT14R13 is the Downlink (BX10-D) variant with Tx at 1490 nm and Rx at 1310 nm. The SFP-GE10KT13R14 is the Uplink (BX10-U) variant with Tx at 1310 nm and Rx at 1490 nm. These two must be paired together at opposite ends of a single-mode fibre link to establish a bidirectional 1GbE connection.

Q: Can this SFP be used on Juniper EX Series switches?
A: Yes. The SFP-GE10KT14R13 is supported on Juniper EX Series switches as well as M Series, MX Series, and T Series routers. Always verify compatibility with your specific platform and Junos OS version via Juniper's Hardware Compatibility Tool.

Q: Does this transceiver support Digital Diagnostics Monitoring (DDM)?
A: Yes. The SFP-GE10KT14R13 supports DDM (also known as DOM), allowing network administrators to monitor real-time parameters such as optical transmit/receive power, temperature, supply voltage, and bias current directly from compatible Juniper management interfaces.

Q: What type of fibre cable is required for this SFP?
A: This transceiver requires single-mode fibre (SMF) cable with a 9/125 µm core, terminated with a Simplex LC connector. Only a single fibre strand is needed for the full duplex link, as it uses bidirectional (BiDi) wavelength division to carry both transmit and receive traffic.

Q: Can I purchase the SFP-GE10KT14R13 in Australia through IP Trading?
A: Yes. IP Trading (iptrading.com.au) supplies Juniper transceivers including the SFP-GE10KT14R13 and ships across Australia. Contact the team for volume pricing, compatibility advice, and to source the matching BX10-U uplink SFP if required.

Q: What is the maximum distance this SFP can support?
A: The SFP-GE10KT14R13 supports a maximum reach of 10 km over single-mode fibre at 1000 Mbps, making it suitable for campus and metropolitan-area network connections between buildings or facilities.
