Juniper SFP-GE10KT13R15 | 1G SFP BiDi Transceiver, 1000BASE-BX10 Uplink, Tx1310/Rx1550nm, 10km

Name: Juniper SFP-GE10KT13R15 | 1G SFP BiDi Transceiver, 1000BASE-BX10 Uplink, Tx1310/Rx1550nm, 10km
Brand: Juniper
SKU: SFP-GE10KT13R15
Price: 344.33 AUD
Availability: BackOrder

Authorised Juniper Partner

SKU:SFP-GE10KT13R15

Stock Status: Enquire

$344.33 inc. GST

$313.03 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Juniper SFP-GE10KT13R15 is a 1 Gbps BiDi (bidirectional) SFP transceiver designed for 1000BASE-BX10 UPLINK applications over a single strand of single-mode fibre (SMF). Transmitting at 1310 nm and receiving at 1550 nm, it delivers a 10 km reach via a simplex LC connector — halving your fibre cabling costs compared to conventional dual-strand transceivers. Digital Diagnostic Monitoring (DDM) provides real-time visibility into transceiver health, including temperature, voltage, and optical power levels.

This UPLINK transceiver must be paired with a compatible DOWNLINK SFP such as the SFP-GE10KT15R13 or SFP-GE10KT14R13. It is MSA-compliant and supported across a broad range of Juniper platforms including MX240, MX480, MX960, M120, M320, T640, T1600, and E-Series routers. Operating across standard temperatures (0 to 70°C), it is suited to enterprise and service provider environments.

Features

- Bidirectional (BiDi) transmission over a single fibre strand — cuts fibre cabling costs by up to 50%
- Digital Diagnostic Monitoring (DDM) for real-time reporting of optical power, temperature, and voltage
- Must be paired with a compatible DOWNLINK SFP (e.g., SFP-GE10KT15R13 or SFP-GE10KT14R13) at the remote end
- Broad Juniper platform compatibility: MX240, MX480, MX960, M120, M320, T320, T640, T1600, E120, E320, M7i, M10i, M40e and more
- MSA (Multi-Source Agreement) compliant for interoperability assurance
- Standard operating temperature range supports typical enterprise and data centre environments

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form Factor: SFP
- Data Rate: 1 Gbps (1000BASE-BX10)
- Mode: UPLINK (BiDi / Bidirectional)
- Tx Wavelength: 1310 nm
- Rx Wavelength: 1550 nm
- Fibre Type: Single-Mode Fibre (SMF), 9/125 µm, Single-Strand
- Connector: LC Simplex
- Reach: 10 km
- Digital Diagnostic Monitoring (DDM): Yes
- Operating Temperature: Standard (0°C to 70°C)
- MSA Compliant: Yes

FAQs

Q: What does 'UPLINK' mean for this transceiver, and what does it need at the other end?
A: The SFP-GE10KT13R15 is the UPLINK end of a BiDi pair, transmitting at 1310 nm and receiving at 1550 nm. At the remote end, you must install a compatible DOWNLINK SFP — such as the SFP-GE10KT15R13 (Tx 1550/Rx 1310 nm) or SFP-GE10KT14R13 — to complete the bidirectional link over a single fibre strand.

Q: Which Juniper devices are compatible with the SFP-GE10KT13R15?
A: This transceiver is supported on a wide range of Juniper routers and switches including the MX240, MX480, MX960, M7i, M10i, M40e, M120, M320, T320, T640, T1600, E120, and E320. Always verify compatibility with your specific platform and Junos version before purchasing.

Q: What fibre type and connector does this SFP require?
A: The SFP-GE10KT13R15 uses a single strand of 9/125 µm single-mode fibre (SMF) with a simplex LC connector, supporting a link distance of up to 10 km.

Q: Does this transceiver support Digital Diagnostic Monitoring (DDM)?
A: Yes. DDM (also known as DOM) is supported, allowing network administrators to monitor real-time transceiver parameters such as optical transmit/receive power, supply voltage, laser bias current, and temperature directly from the Juniper management interface.

Q: Can I use this SFP with non-Juniper equipment?
A: The SFP-GE10KT13R15 is MSA (Multi-Source Agreement) compliant, which means it may be physically compatible with other vendors' equipment. However, Juniper sells and validates it for use on Juniper platforms. Third-party compatibility should be independently verified before deployment.
