Juniper SFP-GE10KT13R14 | 1GbE BiDi SFP Transceiver, SMF, Tx 1310nm/Rx 1490nm, Uplink, 10km

Name: Juniper SFP-GE10KT13R14 | 1GbE BiDi SFP Transceiver, SMF, Tx 1310nm/Rx 1490nm, Uplink, 10km
Brand: Juniper
SKU: SFP-GE10KT13R14
Price: 338.08 AUD
Availability: BackOrder

Authorised Juniper Partner

SKU:SFP-GE10KT13R14

Stock Status: Enquire

$338.08 inc. GST

$307.35 ex. GST

Sale Stock Status: Enquire

Shipping calculated at checkout.

Quantity

Description

The Juniper SFP-GE10KT13R14 is a 1000BASE-BX10 BiDi SFP transceiver designed for Gigabit Ethernet over a single strand of single-mode fibre (SMF) at distances up to 10 km. As the UPLINK variant, it transmits at 1310 nm and receives at 1490 nm via a simplex LC connector, making it ideal for cost-efficient fibre deployments where only one fibre strand is available. It must be paired with a compatible DOWNLINK transceiver (e.g. SFP-GE10KT14R13) at the remote end.

Compliant with IEEE 802.3-2005 (1000BASE-BX10-U), this hot-pluggable SFP operates at standard temperature (0°C to 70°C) and is compatible with Juniper M Series, MX Series, T Series, and E Series platforms including MX240, MX480, MX960, T640, and ERX series.

Features

- Bidirectional (BiDi) transmission over a single strand of SMF, reducing fibre infrastructure costs by up to 50%
- UPLINK variant — must be paired with a DOWNLINK SFP (e.g. SFP-GE10KT14R13) at the remote end
- Hot-pluggable SFP form factor for easy installation and replacement without powering down the host system
- Compliant with IEEE 802.3-2005 (1000BASE-BX10-U) industry standard
- Supports 10 km reach over 9/125 µm single-mode fibre with simplex LC connector
- Compatible with Juniper M, MX, T, and E Series routing platforms
- Standard operating temperature range (0°C to 70°C) suitable for data centre environments

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form Factor: SFP (Small Form-factor Pluggable)
- Data Rate: 1000 Mbps (1 GbE)
- Standard: 1000BASE-BX10-U (IEEE 802.3-2005)
- Transmission Distance: Up to 10 km
- Fiber Type: Single-Mode Fiber (SMF), 9/125 µm
- Transmit Wavelength (Tx): 1310 nm (1260–1360 nm range)
- Receive Wavelength (Rx): 1490 nm (1480–1500 nm range)
- Connector: Simplex LC
- Direction: Bidirectional (BiDi) — UPLINK
- Average Launch Power: –9 to –3 dBm
- Average Receive Power: –19.5 to –3 dBm
- Receiver Saturation: –3 dBm
- Operating Temperature: 0°C to 70°C (Standard)
- Supply Voltage: 3.3V

FAQs

Q: What is the difference between this transceiver and the SFP-GE10KT14R13?
A: The SFP-GE10KT13R14 is the UPLINK variant, transmitting at 1310 nm and receiving at 1490 nm. The SFP-GE10KT14R13 is the DOWNLINK variant, transmitting at 1490 nm and receiving at 1310 nm. These two must be paired together at opposite ends of a BiDi fibre link — they are not interchangeable.

Q: What type of fibre cable does this transceiver require?
A: This transceiver requires single-mode fibre (SMF) cable with a 9/125 µm core diameter and a simplex LC connector. It is not compatible with multimode fibre or duplex LC patch leads.

Q: Which Juniper platforms is the SFP-GE10KT13R14 compatible with?
A: This SFP is compatible with a wide range of Juniper Networks equipment including M Series (M7i, M10i, M40e, M120, M320), MX Series (MX240, MX480, MX960), T Series (T320, T640, T1600), E Series (E120, E320), and ERX Series routers. Always verify compatibility with your specific chassis and line card.

Q: Can I use this transceiver in a standard SFP port on non-Juniper equipment?
A: The SFP-GE10KT13R14 is a Juniper-branded transceiver intended for use in Juniper platforms. While it follows the SFP MSA form factor and 1000BASE-BX10 standard, compatibility with third-party equipment is not guaranteed and should be verified with the respective vendor.

Q: Is this transceiver suitable for outdoor or industrial environments?
A: This is a standard-temperature SFP rated for 0°C to 70°C, making it suitable for indoor, temperature-controlled environments such as data centres and equipment rooms. For harsh or outdoor deployments requiring extended temperature ranges, a different variant would be needed.

Q: Can I purchase the SFP-GE10KT13R14 in Australia from IP Trading?
A: Yes. IP Trading (iptrading.com.au) is an Australian-owned and operated IT hardware reseller based in Australia since 2001. You can order the SFP-GE10KT13R14 directly online, with local support and competitive pricing for B2B customers.
