• Silver metal juniper sfp 1ge lx transceiver with black plastic connector for 1000base lx smf and mmf networks
1 1

Juniper

Juniper SFP-1GE-LX | 1GE SFP Transceiver, 1000BASE-LX, SMF 10km/MMF 550m, Ext Temp

Juniper SFP-1GE-LX | 1GE SFP Transceiver, 1000BASE-LX, SMF 10km/MMF 550m, Ext Temp

SFP-1GE-LX

Stock Status: Enquire

$711.89 AUD
$711.89 AUD
$711.89 AUD
Sale Stock Status: Enquire
Taxes included. Shipping calculated at checkout.

Description

The Juniper SFP-1GE-LX is a 1000BASE-LX Gigabit Ethernet SFP transceiver designed for enterprise and service provider deployments requiring reliable fibre connectivity over extended distances. Operating at 1310nm, it supports up to 10km on single-mode fibre (SMF 9/125 µm) or 550m on multimode fibre (MMF 50/125 or 62.5/125 µm) via a duplex LC connector, making it a versatile choice for campus backbone and inter-building links. The extended operating temperature range of -5 to +70°C suits deployments in environments where standard commercial-grade optics fall short.

Compliant with IEEE 802.3z and SFP MSA standards, this hot-pluggable module operates on a single +3.3V supply and is RoHS certified. It is validated for use with Juniper JX Series platforms and is Class 1 laser certified (IEC 60825-1). Order today from iptrading.com.au — your local source for enterprise-grade networking solutions.

Features

- Hot-pluggable SFP form factor for easy installation and replacement
- Extended temperature operation (-5°C to +70°C) for demanding environments
- Dual fibre support: SMF up to 10km and MMF up to 550m from a single SKU
- Duplex LC connector interface — compatible with standard LC fibre patch panels
- Single +3.3V power supply for simple integration
- IEEE 802.3z 1000BASE-LX compliant for broad interoperability
- Class 1 laser product certified to IEC 60825-1
- RoHS compliant construction
- Validated for Juniper JX Series platforms

Warranty

Juniper products are supplied with standard manufacturer warranty terms, which vary by product and can range from 1 year through to limited lifetime coverage. IP Trading can also provide Juniper J-Care warranty and support extensions for customers who need longer coverage or enhanced support options. https://support.juniper.net/support/warranty/

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form Factor: SFP (Small Form-factor Pluggable)
- Standard: 1000BASE-LX (IEEE 802.3z)
- Data Rate: 1 Gbps (1000 Mbit/s)
- TX Wavelength: 1310nm
- Max Reach (SMF): 10km on 9/125 µm single-mode fibre
- Max Reach (MMF): 550m on 50/125 µm or 62.5/125 µm multimode fibre
- Connector: Duplex LC
- Operating Temperature: Extended -5°C to +70°C
- Power Supply: +3.3V
- Compliance: SFP MSA, IEEE 802.3z, IEC 60825-1 (Class 1 Laser), RoHS

FAQs

Q: What fibre types does the SFP-1GE-LX support?
A: The SFP-1GE-LX supports both single-mode fibre (SMF) with a reach of up to 10km on 9/125 µm fibre, and multimode fibre (MMF) with a reach of up to 550m on 50/125 µm or 62.5/125 µm fibre. Both use a duplex LC connector.

Q: Why choose the extended temperature variant over a standard commercial-grade optic?
A: The SFP-1GE-LX operates from -5°C to +70°C, compared to the standard 0–70°C range. This makes it suitable for environments with greater thermal variation, such as industrial facilities, outdoor enclosures, or data centres with inconsistent cooling.

Q: Which Juniper platforms is this transceiver compatible with?
A: The SFP-1GE-LX is validated for use with Juniper JX Series router platforms. As an SFP MSA-compliant module, it may also be compatible with other Juniper equipment that supports standard 1000BASE-LX SFP optics — consult Juniper's Hardware Compatibility Tool (HCT) for your specific platform.

Q: Is this transceiver hot-pluggable?
A: Yes, the SFP-1GE-LX is fully hot-pluggable, allowing it to be inserted or removed from a live system without requiring a reboot or service interruption, provided the host platform supports this feature.

Q: Can I purchase the Juniper SFP-1GE-LX in Australia from IP Trading?
A: Yes. iptrading.com.au stocks Juniper optic modules including the SFP-1GE-LX for Australian B2B customers. Contact our team for volume pricing, lead times, and compatibility advice for your network environment.

Q: Does this transceiver require any licensing to operate?
A: No software licence is required to use the SFP-1GE-LX. It is a standard plug-and-play optical transceiver compliant with SFP MSA and IEEE 802.3z specifications.
